Main Frame Assembly
Parts (17)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | TCHS061535 Stem, Alloy, Blk | Stem, Alloy, Blk | 1 | $68.68 | Obsolete | View Details |
| 2 | TCHS121259 Headset, Spacer, 10Mm, Alu, Blk | Headset, Spacer, 10Mm, Alu, Blk | 1 | $3.37 | Available to order | 1 |
| 3 | TCHS121260 Headset, Spacer, 5Mm, Alu, Blk | Headset, Spacer, 5Mm, Alu, Blk | 2 | $3.37 | Available to order | 2 |
| 4 | TCHS031297 RR Shock, DV22AR, L165, 250LB | RR Shock, DV22AR, L165, 250LB | 1 | $97.87 | Available to order | 1 |
| 5 | TCHS112214 Chain Adj, 12Mm, 2 Sets | Chain Adj, 12Mm, 2 Sets | 1 | $20.25 | Available to order | 1 |
| 6 | TPLA081352 Chain Guard, Lower, STL, Blk | Chain Guard, Lower, STL, Blk | 1 | $14.85 | Out of Stock | Notify Me |
| 7 | TCHS081716 SA Cover, STL, Red | SA Cover, STL, Red | 1 | $11.47 | Available to order | 1 |
| 8 | TCHS081885 Swing Arm Axle, 15Mm, STL | Swing Arm Axle, 15Mm, STL | 1 | $30.37 | Available to order | 1 |
| 9 | TFIX012607 Bolt Kit, M8X45Mm, 2 Sets | Bolt Kit, M8X45Mm, 2 Sets | 1 | $3.37 | Available to order | 1 |
| 10 | TCHS011257 Footpeg Kit, Cast, Red | Footpeg Kit, Cast, Red | 1 | $82.35 | Available to order | 1 |
| 11 | TCHS122535 Headset, Sealed Bearings | Headset, Sealed Bearings | 1 | $37.80 | Available to order | 1 |
| 12 | TCHS051551 Handlebar, OSET, Alloy, Blk | Handlebar, OSET, Alloy, Blk | 1 | $74.25 | Available to order | 1 |
| 14 | TFIX051834 Bearing, 15X32X9Mm, STL, White | Bearing, 15X32X9Mm, STL, White | 4 | $9.85 | Available to order | 4 |
| 15 | TCHS022612 Forks - DNM USD24, L-410, Gold | Forks - DNM USD24, L-410, Gold | 1 | $450.00 | Available to order | 1 |
| 17 | TCHS081176 Swing Arm, MX10, STL, Blk | Swing Arm, MX10, STL, Blk | 1 | $168.75 | Available to order | 1 |
| 18 | TCHS072616 Frame, MX10, Fr, STL, Blk | Frame, MX10, Fr, STL, Blk | 1 | $319.93 | Available to order | 1 |
| 19 | TCHS022400 Fork Damping Kit | Fork Damping Kit | 1 | $228.15 | Available to order | 1 |
