Gear Selectors & Pedal
Parts (45)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T1190286 Bearing, Ball | Bearing, Ball | 1 | $48.95 | Out of Stock | Notify Me |
| 2 | T1191135 Shaft, Selector Fork | Shaft, Selector Fork | 1 | $44.34 | Available to order | 1 |
| 3 | T1198001 Selector Drum, 6 Speed | Selector Drum, 6 Speed | 1 | $341.71 | Out of Stock | Notify Me |
| 4 | T1198007 Detent Wheel | Detent Wheel | 1 | $38.49 | Available to order | 1 |
| 5 | T3050302 Capscrew, Skt/Hd, M6 x 35 | Capscrew, Skt/Hd, M6 x 35 | 1 | $1.21 | Available to order | 1 |
| 6 | T1198008 Selector Fork, Output | Selector Fork, Output | 1 | $154.71 | Out of Stock | Notify Me |
| 7 | T1198009 Selector Fork, Output | Selector Fork, Output | 1 | $154.71 | Out of Stock | Notify Me |
| 8 | T1198010 Selector Fork, Input | Selector Fork, Input | 1 | $163.05 | Out of Stock | Notify Me |
| 9 | T1198003 Gearchange Shaft Assembly | Gearchange Shaft Assembly | 1 | $167.77 | Out of Stock | Notify Me |
| 10 | T1198765 Pivot Plate | Pivot Plate | 1 | $12.55 | Available to order | 1 |
| 11 | T1192522 Spring, Coil, Pivot Plate | Spring, Coil, Pivot Plate | 1 | $10.90 | Available to order | 1 |
| 12 | T3550236 Washer, 14 x 20 x 1.6 | Washer, 14 x 20 x 1.6 | 2 | $2.95 | Available to order | 2 |
| 13 | T3502535 Circlip, Din 471, Dia. 14.0 | Circlip, Din 471, Dia. 14.0 | 2 | $1.91 | Available to order | 2 |
| 14 | T1198013 Gearchange Return Spring | Gearchange Return Spring | 1 | $10.87 | Backorder — Early August 2026 | 1 |
| 15 | T3550444 Washer, 15.5 x 25 | Washer, 15.5 x 25 | 3 | $1.78 | Available to order | 3 |
| 16 | T3501111 E-Clip, 13-18 | E-Clip, 13-18 | 2 | $1.21 | Available to order | 2 |
| 17 | T1198012 Gearchange Actuator Knuckle | Gearchange Actuator Knuckle | 1 | $33.57 | Available to order | 1 |
| 18 | T1198011 Gearchange Actuator Shaft | Gearchange Actuator Shaft | 1 | $86.31 | Available to order | 1 |
| 19 | T3500290 Circlip, Int, 20 x 1 | Circlip, Int, 20 x 1 | 1 | $2.80 | Available to order | 1 |
| 20 | T3600088 Seal, Oil, 14 x 22 x 4.5 | Seal, Oil, 14 x 22 x 4.5 | 1 | $6.39 | Available to order | 1 |
| 21 | T3201977 Bolt, HHF, Lghtd, M8 x 16, Enc | Bolt, HHF, Lghtd, M8 x 16, Enc | 1 | $5.12 | Available to order | 1 |
| 22 | T1198006 Retainer Plate | Retainer Plate | 1 | $18.78 | Out of Stock | Notify Me |
| 23 | T3331044 Screw, Pan/Hd, Tx, M6 x 16, Slv | Screw, Pan/Hd, Tx, M6 x 16, Slv | 2 | $0.97 | Available to order | 2 |
| 24 | T1198002 Detent Arm Assembly | Detent Arm Assembly | 1 | $28.68 | Available to order | 1 |
| 25 | T1194200 Dowel, Detent Arm | Dowel, Detent Arm | 1 | $9.31 | Backorder — Early August 2026 | 1 |
| 26 | T3000205 Dowel, Solid, 8 x 35 | Dowel, Solid, 8 x 35 | 1 | $0.91 | Available to order | 1 |
| 27 | T3331499 Screw, Pan/Hd, Tx, M6 x 35 | Screw, Pan/Hd, Tx, M6 x 35 | 1 | $2.37 | Available to order | 1 |
| 28 | T3554200 Washer, Hardened, 6.5 x 16 x 1 | Washer, Hardened, 6.5 x 16 x 1 | 1 | $3.77 | Available to order | 1 |
| 29 | T1198004 Spring, Detent Arm | Spring, Detent Arm | 1 | $10.98 | Available to order | 1 |
| 30 | T3331041 Screw, Pan/Hd, Tx, M6 x 25, Enc | Screw, Pan/Hd, Tx, M6 x 25, Enc | 1 | $1.06 | Available to order | 1 |
| 31 | T3000042 Spacer, Turned | Spacer, Turned | 1 | $1.72 | Available to order | 1 |
| 32 | T3555004 Washer, 6.4 x 14 x 1.6 | Washer, 6.4 x 14 x 1.6 | 1 | $1.40 | Available to order | 1 |
| 33 | T1190207 Keeper Plate | Keeper Plate | 2 | $20.60 | Out of Stock | Notify Me |
| 34 | T3550090 Washer, Thrust | Washer, Thrust | 1 | $4.12 | Available to order | 1 |
| 35 | T3500044 E Circlip | E Circlip | 1 | $0.97 | Available to order | 1 |
| 36 | T2083888 Clamp, Gearchange Assy | Clamp, Gearchange Assy | 1 | $87.73 | Available to order | 1 |
| 37 | T3050334 Screw, Cap/Hd, M6 x 20, Slv | Screw, Cap/Hd, M6 x 20, Slv | 1 | $1.51 | Available to order | 1 |
| 38 | T2082842 Gearchange Pedal Assy, Black | Gearchange Pedal Assy, Black | 1 | $119.49 | Available to order | 1 |
| 39 | T2082795 Rubber, Gearchange Pedal | Rubber, Gearchange Pedal | 1 | $9.02 | Backorder — Early August 2026 | 1 |
| 40 | T3331520 Bolt, Shld, M8 x 1.25, Slv, Enc | Bolt, Shld, M8 x 1.25, Slv, Enc | 1 | $10.63 | Available to order | 1 |
| 41 | T2082360 Gearchange Rod | Gearchange Rod | 1 | $28.80 | Available to order | 1 |
| 43 | T2082461 Bracket, Connector, TSA | Bracket, Connector, TSA | 1 | $8.76 | Available to order | 1 |
| 44 | T2504512 S Clip, 3.5 - 4.5 | S Clip, 3.5 - 4.5 | 1 | $8.18 | Available to order | 1 |
| 45 | T3350410 Nut, Thin, M6, Slv | Nut, Thin, M6, Slv | 1 | $4.20 | Out of Stock | Notify Me |
| 46 | T3350414 Nut, Thin, LH, M6, Slv | Nut, Thin, LH, M6, Slv | 1 | $4.20 | Available to order | 1 |
