Loading schematic...
Transmission
Parts (16)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T1181201 Input Shaft Assembly | Input Shaft Assembly | 1 | $836.47 | Available to order | 1 |
| 2 | T1181399 Output Shaft Assembly | Output Shaft Assembly | 1 | $2075.54 | Available to order | 1 |
| 3 | T3555040 Washer, 26 x 39.8 x 1.5 | Washer, 26 x 39.8 x 1.5 | 2 | $5.40 | Available to order | 2 |
| 4 | T1181220 Sleeve, Needle Bearing, Plain | Sleeve, Needle Bearing, Plain | 1 | $62.46 | Available to order | 1 |
| 5 | T3800800 Bearing, Needle, K25 x 32 x 16 | Bearing, Needle, K25 x 32 x 16 | 2 | $17.21 | Out of Stock | Notify Me |
| 6 | T3500160 Circlip, Int, 40 x 1.75 | Circlip, Int, 40 x 1.75 | 1 | $1.44 | Available to order | 1 |
| 7 | T1181210 Housing, Bearing, Input | Housing, Bearing, Input | 1 | $134.96 | Available to order | 1 |
| 8 | T3803101 Bearing, D Row Angle, 30 x 62 x 23.8 | Bearing, D Row Angle, 30 x 62 x 23.8 | 1 | $77.35 | Available to order | 1 |
| 9 | T1181334 Plate, Retaining, Input | Plate, Retaining, Input | 1 | $10.87 | Out of Stock | Notify Me |
| 10 | T3335017 Screw, But/Hd, TX, M8 x 30, Enc | Screw, But/Hd, TX, M8 x 30, Enc | 4 | $5.72 | Available to order | 4 |
| 11 | T1181221 Sleeve, Needle Bearing, Dowel | Sleeve, Needle Bearing, Dowel | 1 | $62.46 | Available to order | 1 |
| 12 | T1181333 Plate, Retaining, Output | Plate, Retaining, Output | 1 | $9.88 | Out of Stock | Notify Me |
| 13 | T1164003 Shim, Retainer Plate, 0.3mm | Shim, Retainer Plate, 0.3mm | — | $6.05 | Available to order | 1 |
| 13 | T1164004 Shim, Retainer Plate, 0.4mm | Shim, Retainer Plate, 0.4mm | — | $6.88 | Available to order | 1 |
| 13 | T1164005 Shim, Retainer Plate, 0.5mm | Shim, Retainer Plate, 0.5mm | — | $7.56 | Available to order | 1 |
| 14 | T3335018 Screw, But/HD, TX, M8 x 25, Enc | Screw, But/HD, TX, M8 x 25, Enc | 4 | $3.35 | Available to order | 4 |
