Triumph Rocket III Indicators — OEM Parts Diagram

Engle Motors is your source for OEM Triumph parts and accessories with free shipping on orders of $100+!OEM Triumph parts — free shipping over $100!

Loading schematic...

What Our Customers Say

5 out of 5 based on 710 reviews

View all reviews →

“I like the procedure of verifying the part # with my motorcycle VIN#.”

M. Armfield · LOS ALTOS, CA · Mar 2026

“It would be nice to have better drawings of the parts. These were fuzzy and difficult to make out.”

M. Cohen · Pasadena, CA · Mar 2026

“EASY TO USE WEBSITE, AND GREAT SERVICE!”

J. SHEETS · CINCINNATI, OH · Feb 2026

“You guys are awesome! I Always use you guys for parts! Your diagrams are easy to move through. I will say the cooling system side was a little hard to figure out but praise be that theres a search bar! All n' all, 10/10! Rock on!”

N. Drinkall · BUHL, ID · Feb 2026

“Very efficient process... no hoping on a smooth delivery process. :-)”

P. De Keersmaecker · JACKSONVILLE, FL · Feb 2026

“Thank you, search was easy and glad I found you guys.”

P. Melia · SAINT PETERSBURG, FL · Feb 2026

#	Part Number	Description	Qty	Price	Status
1	T2701100 Indicator, Front	Indicator, Front	1	$65.49	Available to order	1 Ships within 3–7 business days
2	T2701104 Indicator, Front, RH	Indicator, Front, RH	1	$65.49	Available to order	1 Ships within 3–7 business days
3	T2700445 Lens	Lens	4	$12.76	Available to order	4 Ships within 3–7 business days
4	2700032-T0301 Bulb	Bulb	4	$4.52	Obsolete	View Details
5	T2700428 Screw	Screw	6	$1.21	Available to order	6 Ships within 3–7 business days
8	T2701110 Bracket, Indicator, Front, LH	Bracket, Indicator, Front, LH	1	$54.20	Available to order	1 Ships within 3–7 business days
9	T3330931 Screw, Csk, M6 x 20. Slv	Screw, Csk, M6 x 20. Slv	2	$7.22	Available to order	2 Ships within 3–7 business days
10	T3205063 Bolt, HHF, Lghtd, M6 x 16, Slv	Bolt, HHF, Lghtd, M6 x 16, Slv	2	$3.50	Available to order	2 Ships within 3–7 business days
11	T3350088 Domenut, Locking, M6	Domenut, Locking, M6	2	$1.79	Available to order	2 Ships within 3–7 business days
12	T2701111 Bracket, Indicator, Front, RH	Bracket, Indicator, Front, RH	1	$54.20	Available to order	1 Ships within 3–7 business days
13	T2040884 Clip, Twin, Speedo, Brake	Clip, Twin, Speedo, Brake	3	$4.74	Backorder — Late August 2026	3
14	T3701094 P Clip, Dia 4.4, Black	P Clip, Dia 4.4, Black	2	$3.24	Available to order	2 Ships within 3–7 business days
15	T3330642 Screw, Philips, M4 x 8, Plastic	Screw, Philips, M4 x 8, Plastic	2	$2.85	Out of Stock	Notify Me
16	T2700521 Indicator Assy, Rear, LH	Indicator Assy, Rear, LH	1	$65.49	Available to order	1 Ships within 3–7 business days
17	T2700523 Indicator Body	Indicator Body	2	$46.64	Available to order	2 Ships within 3–7 business days
19	T2700441 Screw	Screw	2	$1.21	Available to order	2 Ships within 3–7 business days
20	T2700522 Indicator Assy, Rear, RH	Indicator Assy, Rear, RH	1	$65.49	Available to order	1 Ships within 3–7 business days
21	T3551140 Washer, Serrated, Lock, M10	Washer, Serrated, Lock, M10	2	$0.97	Available to order	2 Ships within 3–7 business days
22	T3550229 Washer, 15.2 x 10 x 1, Plated	Washer, 15.2 x 10 x 1, Plated	2	$1.07	Available to order	2 Ships within 3–7 business days
23	T3350302 Nut, M10, Slv	Nut, M10, Slv	2	$0.89	Available to order	2 Ships within 3–7 business days
24	T2704020 Number Plate Bracket, Reflector	Number Plate Bracket, Reflector	1	$31.76	Available to order	1 Ships within 3–7 business days
25	T2707111 Reflex Reflector	Reflex Reflector	1	$9.88	Available to order	1 Ships within 3–7 business days
26	T3350003 Locknut, Flanged, M6 x 1	Locknut, Flanged, M6 x 1	1	$0.67	Available to order	1 Ships within 3–7 business days
27	T3550253 Washer, Dia 5 mm, Retaining	Washer, Dia 5 mm, Retaining	2	$0.97	Available to order	2 Ships within 3–7 business days
28	T2700760 Assembly, Reflector, Lhs	Assembly, Reflector, Lhs US, CA, AR, ID & ZA Only	1	$18.25	Available to order	1 Ships within 3–7 business days
29	T2700750 Bracket, Reflector, LHS	Bracket, Reflector, LHS US, CA, AR, ID & ZA Only	1	$12.16	Available to order	1 Ships within 3–7 business days
30	T2700443 Reflector, Oval, Red	Reflector, Oval, Red US, CA, AR, ID & ZA Only	2	$6.14	Available to order	2 Ships within 3–7 business days
31	T2700761 Assembly, Reflector, Rhs	Assembly, Reflector, Rhs US, CA, AR, ID & ZA Only	1	$18.25	Available to order	1 Ships within 3–7 business days
32	T2700751 Bracket, Reflector, RHS	Bracket, Reflector, RHS US, CA, AR, ID & ZA Only	1	$12.16	Available to order	1 Ships within 3–7 business days
33	T2700332 Reflector, Amber, Oval	Reflector, Amber, Oval US, CA, AR, ID & ZA Only	2	$6.39	Available to order	2 Ships within 3–7 business days

Part Number

Price

T2701100

Indicator, Front

$65.49

Ships within 3–7 business days

T2701104

Indicator, Front, RH

$65.49

Ships within 3–7 business days

T2700445

Lens
