Loading schematic...
Tall Passenger Backrest & Luggage Rack
Parts (14)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | A9738070 Passenger Backrest & L/Rack High Kit | Passenger Backrest & L/Rack High Kit Back pad & badge not included. Badge p/n is A9738002 & Back Pad p/n is A9708177 | 1 | $310.00 | Obsolete | View Details |
| 2 | A9733500 Passenger Backrest & Plug Assy, High | Passenger Backrest & Plug Assy, High * PART NO LONGER AVAILABLE * | 1 | $159.00 | Obsolete | View Details |
| 3 | A9733502 Luggage Rack | Luggage Rack | 1 | $47.50 | Obsolete | View Details |
| 4 | A9750265 Pressing Support LH | Pressing Support LH | 1 | $55.00 | Obsolete | View Details |
| 5 | A9750266 Pressing Support RH | Pressing Support RH | 1 | $54.00 | Obsolete | View Details |
| 6 | A9750282 Mudguard Cover Rear LH | Mudguard Cover Rear LH | 1 | $60.00 | Obsolete | View Details |
| 7 | A9750283 Mudguard Cover Rear RH | Mudguard Cover Rear RH | 1 | $113.40 | Backorder — Late July 2026 | 1 |
| 9 | A9910052 Screw, Domehead, M6 x 12 | Screw, Domehead, M6 x 12 | 4 | $2.70 | Available to order | 4 |
| 10 | A9910835 Bolt, M8 x 1.25 x 35, HHF | Bolt, M8 x 1.25 x 35, HHF | 4 | $5.30 | Obsolete | View Details |
| 11 | T3350004 Locknut, Flanged, M8 x 1.25 | Locknut, Flanged, M8 x 1.25 | 4 | $2.45 | Available to order | 4 |
| 12 | T3205254 Bolt, HHF, Lghtd, M8 x 20, Slv | Bolt, HHF, Lghtd, M8 x 20, Slv | 4 | $1.62 | Backorder — Early August 2026 | 4 |
| 13 | T3350700 Nut, Flanged Domed, M8 | Nut, Flanged Domed, M8 | 4 | $2.17 | Available to order | 4 |
| 14 | A9710032 Edge Trim Long | Edge Trim Long | 2 | $1.20 | Obsolete | View Details |
| 15 | A9710033 Edge Trim Short | Edge Trim Short | 2 | $0.30 | Obsolete | View Details |
