Engle Motors is your source for OEM Triumph parts and accessories with free shipping on orders of $100+!OEM Triumph parts — free shipping over $100!
Loading schematic...
Rear Wheel
Parts (23)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 52TA0641 Rear Wheel Assy, Scrambler 400, W/O Tyre | Rear Wheel Assy, Scrambler 400, W/O Tyre | 1 | $717.47 | Available to order | 1 |
| 2 | TA131214 Spindle | Spindle | 1 | $60.84 | Available to order | 1 |
| 3 | TA131221 Damper Coupling | Damper Coupling | 1 | $35.89 | Available to order | 1 |
| 4 | TA131219 Spacer | Spacer | 1 | $5.26 | Available to order | 1 |
| 5 | TA131210 Collar | Collar | 1 | $15.15 | Available to order | 1 |
| 6 | KPBC6303 Bearing Ball, ID17 x OD47 x T14 x C3 | Bearing Ball, ID17 x OD47 x T14 x C3 | 2 | $23.82 | Available to order | 2 |
| 7 | TA131209 Spacer | Spacer | 1 | $52.71 | Available to order | 1 |
| 9 | KEBB4717 Circlip, 47 x 17 | Circlip, 47 x 17 | 1 | $1.93 | Available to order | 1 |
| 10 | DK151012 Oil Seal | Oil Seal | 1 | $2.22 | Available to order | 1 |
| 11 | TA131211 Collar | Collar | 1 | $8.01 | Available to order | 1 |
| 12 | KDAA1630 Plain Washer, Small | Plain Washer, Small | 1 | $0.46 | Available to order | 1 |
| 13 | LCL00005 Nut U Flanged, M16 x 1.5 | Nut U Flanged, M16 x 1.5 | 1 | $6.36 | Available to order | 1 |
| 14 | DK151026 Valve, Tubeless Tyre | Valve, Tubeless Tyre | 1 | $2.25 | Out of Stock | Notify Me |
| 15 | TA131213 Sprocket, 43T | Sprocket, 43T (43 Teeth) | 1 | $124.78 | Available to order | 1 |
| 16 | TA131205 Coupling | Coupling | 1 | $71.71 | Available to order | 1 |
| 17 | DT131214 Oil Seal | Oil Seal | 1 | $5.71 | Available to order | 1 |
| 18 | 39042817 Circlip | Circlip | 1 | $1.97 | Out of Stock | Notify Me |
| 19 | KPAC6205 Bearing Ball Ordinary Clearance | Bearing Ball Ordinary Clearance | 1 | $18.54 | Available to order | 1 |
| 20 | LCL00004 Nut U Flanged, M8 x 1.25 x HT8.5 x Brt | Nut U Flanged, M8 x 1.25 x HT8.5 x Brt | 6 | $1.24 | Available to order | 6 |
| 21 | LAJ00031 Bolt Stud, M8 x 1.25 | Bolt Stud, M8 x 1.25 | 6 | $1.01 | Available to order | 6 |
| 25 | 36TA0137 Chain & Sprocket Kit | Chain & Sprocket Kit | 1 | $206.91 | Available to order | 1 |
| 26 | TA141008 Chain | Chain | 1 | $173.85 | Available to order | 1 |
| 27 | JP551021 Sprocket Drive | Sprocket Drive (14 Teeth) | 1 | $26.80 | Backorder — Mid August 2026 | 1 |
