Fuel Tank/Fuel Pump Fittings
Parts (32)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2401387-NW Fuel Tank Assy | Fuel Tank Assy Crystal White - Includes heat pad, item 29 & tank badges, item 30 | 1 | $1741.80 | Available to order | 1 |
| 1 | T2401387-PG Fuel Tank Assy | Fuel Tank Assy Jet Black - Includes heat pad, item 29 & tank badges, item 30 | 1 | $1443.21 | Available to order | 1 |
| 2 | T2405926 Fuel Level Sender, Tube Type | Fuel Level Sender, Tube Type | 1 | $171.11 | Backorder — Early August 2026 | 1 |
| 3 | T2403892 Pump, Fuel, 3.5 Bar | Pump, Fuel, 3.5 Bar | 1 | $180.73 | Backorder — Mid August 2026 | 1 |
| 4 | T2401887 Seal, Fuel Pump Module | Seal, Fuel Pump Module | 1 | $10.25 | Available to order | 1 |
| 5 | T2400562 Location Plate, Pump | Location Plate, Pump | 1 | $37.09 | Available to order | 1 |
| 6 | T3331234 Screw, Torx, P/H, M6 x 20, Slv | Screw, Torx, P/H, M6 x 20, Slv | 6 | $5.30 | Available to order | 6 |
| 7 | T2405034 Seal, Fuel Filler Cap | Seal, Fuel Filler Cap | 1 | $8.46 | Available to order | 1 |
| 8 | T2400446 Rubber Bush | Rubber Bush | 2 | $3.24 | Out of Stock | Notify Me |
| 9 | T2404416 Spacer, 10 x 129 x 1.55 | Spacer, 10 x 129 x 1.55 | 1 | $16.93 | Out of Stock | Notify Me |
| 10 | T3204087 Bolt, RHHF, M6 x 147, S/S | Bolt, RHHF, M6 x 147, S/S | 1 | $3.50 | Available to order | 1 |
| 11 | T3020605 Grommet, Castellated, Oval | Grommet, Castellated, Oval | 2 | $4.01 | Available to order | 2 |
| 12 | T3010710 Flanged Sleeve, 6.4 x 9.6 x 13.4 | Flanged Sleeve, 6.4 x 9.6 x 13.4 | 2 | $4.12 | Available to order | 2 |
| 13 | T3550266 Washer, Oval, Tabbed, 1.6mm Thick | Washer, Oval, Tabbed, 1.6mm Thick | 2 | $2.00 | Available to order | 2 |
| 14 | T3200148 Bolt, RHHF, M6 x 30, Slv | Bolt, RHHF, M6 x 30, Slv | 2 | $4.45 | Available to order | 2 |
| 15 | T3620016 Hose, Formed, Drain | Hose, Formed, Drain | 1 | $14.66 | Backorder — Early August 2026 | 1 |
| 17 | T3350123 Nut, Captive, M5, Non-Secured | Nut, Captive, M5, Non-Secured | 3 | $2.48 | Available to order | 3 |
| 18 | T3660033 Trim, Tank Flange, 120mm | Trim, Tank Flange, 120mm | 1 | $5.30 | Available to order | 1 |
| 19 | T2401240 Clip, Baffle, Plastic | Clip, Baffle, Plastic | 1 | $4.85 | Out of Stock | Notify Me |
| 20 | T2401262-NW Cover Panel, Spares | Cover Panel, Spares Crystal White | 1 | $537.47 | Available to order | 1 |
| 20 | T2401262-PG Cover Panel, Spares | Cover Panel, Spares Jet Black | 1 | $537.47 | Available to order | 1 |
| 21 | T2305352 Foam Tape, Cover Panel | Foam Tape, Cover Panel | 4 | $5.78 | Available to order | 4 |
| 22 | T3330679 Screw, Csk, M5 x 14, S/S | Screw, Csk, M5 x 14, S/S | 3 | $5.02 | Backorder — Late July 2026 | 3 |
| 23 | T3550094 Washer, Nylon, 12.45x14x0.76 | Washer, Nylon, 12.45x14x0.76 | 3 | $1.10 | Available to order | 3 |
| 24 | T3550265 Washer, M5, C'sunk | Washer, M5, C'sunk | 3 | $4.19 | Available to order | 3 |
| 25 | T2401267 Infill, Fuel Tank, LH | Infill, Fuel Tank, LH | 1 | $18.08 | Available to order | 1 |
| 26 | T2401268 Infill, Fuel Tank, RH | Infill, Fuel Tank, RH | 1 | $18.08 | Available to order | 1 |
| 27 | T3330998 Screw, But/Hd, Skt, M6 x 12, 88, SS/Slv | Screw, But/Hd, Skt, M6 x 12, 88, SS/Slv | 2 | $4.30 | Available to order | 2 |
| 28 | T3590159 Grommet, Rubber, ID8 | Grommet, Rubber, ID8 | 2 | $1.51 | Available to order | 2 |
| 29 | T2405044 Heat Pad, Fuel Tank, Top | Heat Pad, Fuel Tank, Top | 1 | $57.60 | Available to order | 1 |
| 30 | T2409027 Kit, Tank Badges, 140mm | Kit, Tank Badges, 140mm Not Illustrated - Fit to White Tanks - Kit Contains 2 Badges | 1 | $153.52 | Available to order | 1 |
| 30 | T2401884 Tank Badge, 140mm | Tank Badge, 140mm Not Illustrated - Fit to Black Tanks | 2 | $65.62 | Available to order | 2 |
