Throttles/Injectors and Fuel Rail
Parts (29)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T1240699 Throttle body | Throttle body | 1 | $2756.43 | Obsolete | View Details |
| 2 | T1240776 Gasket, Throttle Body | Gasket, Throttle Body | 1 | $2.10 | Available to order | 1 |
| 3 | T3330154 Screw, Torx, PH, M6 x 30 | Screw, Torx, PH, M6 x 30 M6 x 30mm | 6 | $2.90 | Obsolete | View Details |
| 4 | T1290500 Throttle potentiometer | Throttle potentiometer | 1 | $264.04 | Available to order | 1 |
| 5 | T1290501 Plate Retaining | Plate Retaining | 1 | $1.23 | Obsolete | View Details |
| 6 | T1290502 Screw, Throttlepot | Screw, Throttlepot | 2 | $1.27 | Out of Stock | Notify Me |
| 7 | T1240891 Injector | Injector | 3 | $168.02 | Obsolete | View Details |
| 8 | T1245016 O Ring, Injector, Upper | O Ring, Injector, Upper Upper | 3 | $5.24 | Available to order | 3 |
| 9 | T1240355 Lower O Ring, Injector | Lower O Ring, Injector Lower | 3 | $2.95 | Available to order | 3 |
| 10 | T1240894 Clip, Injector | Clip, Injector | 3 | $2.05 | Obsolete | View Details |
| 11 | T1240810 Fuel rail | Fuel rail | 1 | $177.84 | Obsolete | View Details |
| 12 | T1240687 Mounting Rail, Upper | Mounting Rail, Upper Upper | 1 | $12.98 | Obsolete | View Details |
| 13 | T1240738 Screw | Screw | 10 | $3.84 | Obsolete | View Details |
| 14 | T1240735 Screw | Screw | 2 | $1.18 | Obsolete | View Details |
| 15 | T1240889 MOUNTING RAIL, LOWER | MOUNTING RAIL, LOWER Lower | 1 | $29.77 | Obsolete | View Details |
| 16 | T1240719 SCREW, THROTTLE STOP | SCREW, THROTTLE STOP | 1 | $7.46 | Obsolete | View Details |
| 17 | T1240822 Fuel pipe | Fuel pipe PART NO LONGER AVAILABLE - Feed | 1 | $56.04 | Obsolete | View Details |
| 18 | T1240833 Fuel pipe | Fuel pipe Return | 1 | $113.44 | Obsolete | View Details |
| 19 | T3000101 Dowel, Hollow, 8 x 14 | Dowel, Hollow, 8 x 14 | 2 | $3.90 | Backorder — Late August 2026 | 2 |
| 20 | T1240761 Abutment bracket | Abutment bracket | 1 | $4.40 | Obsolete | View Details |
| 21 | T1240181 O ring | O ring | 2 | $6.07 | Available to order | 2 |
| 22 | T1240816 Screw, Self Cutting | Screw, Self Cutting ** Part No Longer Available ** | 2 | $2.62 | Obsolete | View Details |
| 23 | T1240817 Screw | Screw | 2 | $2.18 | Obsolete | View Details |
| 24 | T3700261 CLIP, HOSE | CLIP, HOSE | 1 | $4.12 | Available to order | 1 |
| 25 | T1240749 Restrictor bracket | Restrictor bracket FR & CH | 1 | $9.57 | Out of Stock | Notify Me |
| 26 | T1240748 Restrictor bracket | Restrictor bracket DE | 1 | $33.72 | Obsolete | View Details |
| 27 | T3600053 O ring | O ring | 1 | $2.16 | Obsolete | View Details |
| 28 | T1241165 CPC Kit, White, 8mm | CPC Kit, White, 8mm 8mm | 1 | $57.03 | Unavailable | View Details |
| 29 | T1241170 CPC Kit, Red, 10mm | CPC Kit, Red, 10mm 10mm | 1 | $27.68 | Available to order | 1 |
