Loading schematic...
Transmission
Parts (32)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T1180155 Sleeve Assembly, Input & Output | Sleeve Assembly, Input & Output | 2 | $117.87 | Available to order | 2 |
| 2 | T3800006 Bearing, Needle, K25x32x16 | Bearing, Needle, K25x32x16 | 2 | $17.21 | Available to order | 2 |
| 3 | T1180384 Washer, Thrust, 38 x 2.5 | Washer, Thrust, 38 x 2.5 | 2 | $3.77 | Available to order | 2 |
| 4 | T1181535 Gear, Input, Second | Gear, Input, Second 2nd | 1 | $30.42 | Available to order | 1 |
| 5 | T1181520 Gear input | Gear input 6th | 1 | $91.54 | Obsolete | View Details |
| 6 | T1181063 Bush | Bush | 1 | $63.51 | Obsolete | View Details |
| 7 | T1180281 Washer, Thrust, Input | Washer, Thrust, Input | 2 | $3.70 | Available to order | 2 |
| 8 | T3500003 Circlip, 32mm Shaft | Circlip, 32mm Shaft | 2 | $7.02 | Available to order | 2 |
| 9 | T1181510 Gear input | Gear input 3rd/4th | 1 | $58.59 | Obsolete | View Details |
| 10 | T1181515 Gear input | Gear input 5th | 1 | $92.51 | Obsolete | View Details |
| 11 | T1180598 Input shaft and gear | Input shaft and gear 1st | 1 | $362.99 | Obsolete | View Details |
| 12 | 3800002-T0301 Bearing, Ball, DG2868 GN1C3 | Bearing, Ball, DG2868 GN1C3 | 1 | $43.51 | Backorder — Late July 2026 | 1 |
| 13 | T3800196 Retaining Ring, Bearing | Retaining Ring, Bearing > ENG NO 148349 | 1 | $4.92 | Available to order | 1 |
| 14 | T1181113 Output gear | Output gear 1st | 1 | $133.96 | Obsolete | View Details |
| 15 | T1181508 Output gear | Output gear 5th | 1 | $106.50 | Obsolete | View Details |
| 16 | T3500202 Circlip | Circlip | 3 | $5.60 | Available to order | 3 |
| 17 | T1180292 Washer, Thrust, Output | Washer, Thrust, Output | 3 | $4.85 | Available to order | 3 |
| 18 | T1181525 Output gear | Output gear 3rd | 1 | $109.84 | Obsolete | View Details |
| 19 | T1181135 Bush | Bush | 1 | $42.13 | Obsolete | View Details |
| 20 | T1181530 Output gear | Output gear 4th | 1 | $87.49 | Obsolete | View Details |
| 21 | T1181502 Output gear | Output gear 6th | 1 | $100.20 | Obsolete | View Details |
| 22 | T1181540 Output gear | Output gear PART NO LONGER AVAILABLE - 2nd | 1 | $90.31 | Obsolete | View Details |
| 23 | T1180597 Output shaft | Output shaft | 1 | $315.10 | Obsolete | View Details |
| 24 | T3800132 Bearing, 30 x 62 x 16, DGB | Bearing, 30 x 62 x 16, DGB | 1 | $119.76 | Out of Stock | Notify Me |
| 25 | T3800300 Snap Ring, Ext, 62 x 1.7 | Snap Ring, Ext, 62 x 1.7 | 1 | $3.59 | Available to order | 1 |
| 26 | T3600112 Oil seal | Oil seal | 1 | $11.32 | Available to order | 1 |
| 27 | 1180160-T0301 Distance Sleeve | Distance Sleeve PART NO LONGER AVAILABLE | 1 | $1.80 | Obsolete | View Details |
| 28 | T1180176 Sprocket, Gearbox, 19T | Sprocket, Gearbox, 19T | 1 | $36.83 | Available to order | 1 |
| 29 | T1180181 Washer, Gearbox Sprocket | Washer, Gearbox Sprocket | 1 | $7.56 | Available to order | 1 |
| 30 | T1180175 Nut, Gearbox Sprocket | Nut, Gearbox Sprocket | 1 | $5.56 | Available to order | 1 |
| 31 | T3800101 Bearing, Needle | Bearing, Needle | 1 | $18.85 | Available to order | 1 |
| 32 | T3555016 Thrust Washer, 25 x 35 x 1.0 | Thrust Washer, 25 x 35 x 1.0 | 1 | $4.92 | Available to order | 1 |
