Triumph Street Triple Moto2 Footrests & Mountings — OEM Parts Diagram

Engle Motors is your source for OEM Triumph parts and accessories with free shipping on orders of $100+!OEM Triumph parts — free shipping over $100!

Loading schematic...

What Our Customers Say

5 out of 5 based on 710 reviews

View all reviews →

“I like the procedure of verifying the part # with my motorcycle VIN#.”

M. Armfield · LOS ALTOS, CA · Mar 2026

“It would be nice to have better drawings of the parts. These were fuzzy and difficult to make out.”

M. Cohen · Pasadena, CA · Mar 2026

“EASY TO USE WEBSITE, AND GREAT SERVICE!”

J. SHEETS · CINCINNATI, OH · Feb 2026

“You guys are awesome! I Always use you guys for parts! Your diagrams are easy to move through. I will say the cooling system side was a little hard to figure out but praise be that theres a search bar! All n' all, 10/10! Rock on!”

N. Drinkall · BUHL, ID · Feb 2026

“Very efficient process... no hoping on a smooth delivery process. :-)”

P. De Keersmaecker · JACKSONVILLE, FL · Feb 2026

“Thank you, search was easy and glad I found you guys.”

P. Melia · SAINT PETERSBURG, FL · Feb 2026

#	Part Number	Description	Qty	Price	Status
1	T2088025 Control Plate, LH	Control Plate, LH	1	$124.25	Available to order	1 Ships within 3–7 business days
2	T2082980 Control Plate, RH	Control Plate, RH	1	$124.25	Available to order	1 Ships within 3–7 business days
3	T2082774 Heel Guard, LH	Heel Guard, LH	1	$48.81	Out of Stock	Notify Me
4	T2082773 Heel Guard, RH	Heel Guard, RH	1	$48.81	Available to order	1 Ships within 3–7 business days
5	T2089803 Footrest, Front, LH	Footrest, Front, LH	1	$78.78	Available to order	1 Ships within 3–7 business days
6	T2089804 Footrest, Front, RH	Footrest, Front, RH	1	$78.78	Backorder — Early September 2026	1
7	T2085164 Peg, Bank Angle, 9.2mm	Peg, Bank Angle, 9.2mm	2	$14.07	Available to order	2 Ships within 3–7 business days
8	T2080546 Pin, Pivot, Footrest	Pin, Pivot, Footrest	4	$6.55	Available to order	4 Ships within 3–7 business days
9	T2080819 Return Spring, Footrest	Return Spring, Footrest	2	$6.29	Available to order	2 Ships within 3–7 business days
10	T3500207 Circlip, Ext 8 X 0.89	Circlip, Ext 8 X 0.89	4	$2.85	Available to order	4 Ships within 3–7 business days
11	T3335011 Screw, But/Hd, Tx, M8 x 20	Screw, But/Hd, Tx, M8 x 20	3	$3.50	Available to order	3 Ships within 3–7 business days
12	T3050321 Screw, Cap/Hd, M8 x 20, Slv	Screw, Cap/Hd, M8 x 20, Slv	2	$7.42	Available to order	2 Ships within 3–7 business days
13	T2088256 Footrest Hanger, LH, Black	Footrest Hanger, LH, Black	1	$189.08	Available to order	1 Ships within 3–7 business days
14	T2088257 Footrest Hanger, RH, Blk	Footrest Hanger, RH, Blk	1	$189.08	Available to order	1 Ships within 3–7 business days
15	T2089505 Rear Footrest, LH	Rear Footrest, LH	1	$67.91	Available to order	1 Ships within 3–7 business days
16	T2089504 Rear Footrest, RH	Rear Footrest, RH	1	$67.91	Available to order	1 Ships within 3–7 business days
17	T2081674 Spring, Detent	Spring, Detent	2	$6.39	Available to order	2 Ships within 3–7 business days
18	T2081675 Detent Ball	Detent Ball	2	$1.91	Available to order	2 Ships within 3–7 business days
19	T2081672 Detent Plate	Detent Plate	2	$5.30	Available to order	2 Ships within 3–7 business days
20	T3205653 Bolt, HHF, Lghtd, M8 x 30, Slv	Bolt, HHF, Lghtd, M8 x 30, Slv	4	$1.21	Available to order	4 Ships within 3–7 business days
21	T3051097 Screw, Cap/Hd, M8 x 25, Silver	Screw, Cap/Hd, M8 x 25, Silver	2	$4.12	Available to order	2 Ships within 3–7 business days

Part Number

Price

T2088025

Control Plate, LH

$124.25

Ships within 3–7 business days

T2082980

Control Plate, RH

$124.25

Ships within 3–7 business days

T2082774

Heel Guard, LH
