Loading schematic...
Fuel Tank
Parts (27)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2405758-PG Fuel Tank Assy | Fuel Tank Assy Jet Black | 1 | $1891.09 | Out of Stock | Notify Me |
| 1 | T2405631-HN Fuel Tank Assy | Fuel Tank Assy Competition Green / Frozen Silver > 897562 All Except BR & > 897508 BR Only | 1 | $2587.81 | Backorder — Late July 2026 | 1 |
| 1 | T2405758-DA Fuel Tank Assy | Fuel Tank Assy Morello Red | 1 | $2289.21 | Available to order | 1 |
| 1 | T2405758-GS Fuel Tank Assy | Fuel Tank Assy Ironstone (Matt) > 897562 All Except BR & > 897508 BR Only | 1 | $2289.21 | Available to order | 1 |
| 1 | T2405631-CX Fuel Tank Assy | Fuel Tank Assy Cranberry Red/Frozen Silver - 833614 > 955718 All Except BR & 834264 > 955761 - BR Only | 1 | $2587.81 | Out of Stock | Notify Me |
| 1 | T2405633-DG Fuel Tank Assy | Fuel Tank Assy Korosi Red/Silver Ice - 955719 > All Except BR & 955762 > BR Only | 1 | $2587.81 | Available to order | 1 |
| 1 | T2405758-HS Fuel Tank Assy | Fuel Tank Assy Khaki Green - 897563 > All Except BR & 897509 > BR Only | 1 | $2289.21 | Available to order | 1 |
| 2 | T2409005 Tank Badge Kit, 130mm | Tank Badge Kit, 130mm Fitted to Jet Black, Morello Red & Korosi Red/Silver Ice Bikes - > 982705 | 1 | $131.20 | Available to order | 1 |
| 2 | T2401559 Tank Badge, 130mm | Tank Badge, 130mm Fitted to Jet Black, Morello Red & Korosi Red/Silver Ice Bikes - 982706 > | 2 | $65.62 | Available to order | 2 |
| 2 | T2409019 Tank Badge Kit, 130mm | Tank Badge Kit, 130mm Fitted to Ironstone, Cranberry Red/Frozen Silver & Khaki Bikes - > 980334 | 1 | $65.62 | Available to order | 1 |
| 2 | T2401652 Tank Badge, 130mm | Tank Badge, 130mm Fitted to Ironstone, Cranberry Red/Frozen Silver & Khaki Bikes - 980335 > | 2 | $65.62 | Available to order | 2 |
| 2 | T2405625 Tank Badge, Chrome | Tank Badge, Chrome Fitted to Green/Silver Bikes | 2 | $45.52 | Obsolete | View Details |
| 3 | T2401625 Protective Film | Protective Film | 1 | $5.78 | Available to order | 1 |
| 4 | T2408531 Formed Hose, Tank to Roll Over | Formed Hose, Tank to Roll Over | 1 | $23.76 | Available to order | 1 |
| 5 | T2408900 Formed Hose, Roll Over Drain | Formed Hose, Roll Over Drain | 1 | $5.60 | Backorder — Mid August 2026 | 1 |
| 6 | T2405042 Roll Over Valve | Roll Over Valve | 1 | $40.38 | Out of Stock | Notify Me |
| 7 | T2401440 Fuel Level Sender | Fuel Level Sender | 1 | $34.05 | Available to order | 1 |
| 8 | T3700091 Clip Cable | Clip Cable | 2 | $1.13 | Available to order | 2 |
| 9 | T3700072 Cable Clip, Dia 15-16mm BK | Cable Clip, Dia 15-16mm BK | 1 | $4.12 | Available to order | 1 |
| 10 | T2409056 Bracket, Rear Mount, Fuel Tank | Bracket, Rear Mount, Fuel Tank | 1 | $12.29 | Available to order | 1 |
| 11 | T3205156 Bolt, HHF, Lghtd, M8 x 16, Slv | Bolt, HHF, Lghtd, M8 x 16, Slv | 2 | $1.62 | Available to order | 2 |
| 12 | T3010702 Flanged Sleeve, 6.4 x 10 x 8.5 | Flanged Sleeve, 6.4 x 10 x 8.5 | 2 | $5.78 | Available to order | 2 |
| 13 | T3021100 Grommet, Dia 13 x 1.8 | Grommet, Dia 13 x 1.8 | 2 | $2.85 | Available to order | 2 |
| 14 | T3331191 Screw, Pan/Hd, Tx, M6 x 20, Enc | Screw, Pan/Hd, Tx, M6 x 20, Enc | 2 | $2.10 | Available to order | 2 |
| 15 | T2408787 Rubber, Fuel Tank, Rear Mount | Rubber, Fuel Tank, Rear Mount | 1 | $30.54 | Available to order | 1 |
| 16 | T3331044 Screw, Pan/Hd, Tx, M6 x 16, Slv | Screw, Pan/Hd, Tx, M6 x 16, Slv | 2 | $0.97 | Available to order | 2 |
| 17 | T3350300 Nut, M6 x 1.0, Slv | Nut, M6 x 1.0, Slv | 2 | $0.94 | Available to order | 2 |
