Triumph Street Twin & Speed Twin 900 Handlebars, Top Yoke & Mirrors — OEM Parts Diagram

Engle Motors is your source for OEM Triumph parts and accessories with free shipping on orders of $100+!OEM Triumph parts — free shipping over $100!

Loading schematic...

What Our Customers Say

5 out of 5 based on 710 reviews

View all reviews →

“I like the procedure of verifying the part # with my motorcycle VIN#.”

M. Armfield · LOS ALTOS, CA · Mar 2026

“It would be nice to have better drawings of the parts. These were fuzzy and difficult to make out.”

M. Cohen · Pasadena, CA · Mar 2026

“EASY TO USE WEBSITE, AND GREAT SERVICE!”

J. SHEETS · CINCINNATI, OH · Feb 2026

“You guys are awesome! I Always use you guys for parts! Your diagrams are easy to move through. I will say the cooling system side was a little hard to figure out but praise be that theres a search bar! All n' all, 10/10! Rock on!”

N. Drinkall · BUHL, ID · Feb 2026

“Very efficient process... no hoping on a smooth delivery process. :-)”

P. De Keersmaecker · JACKSONVILLE, FL · Feb 2026

“Thank you, search was easy and glad I found you guys.”

P. Melia · SAINT PETERSBURG, FL · Feb 2026

#	Part Number	Description	Qty	Price	Status
1	T2042349 Handlebar, OD 22.2	Handlebar, OD 22.2	1	$189.89	Out of Stock	Notify Me
2	T2045932 Switchcube, LH	Switchcube, LH	1	$318.46	Available to order	1 Ships within 3–7 business days
3	T2045940 Switchcube, RH	Switchcube, RH	1	$202.96	Available to order	1 Ships within 3–7 business days
4	T2041579 Grip, Handlebar, LH	Grip, Handlebar, LH	1	$18.16	Available to order	1 Ships within 3–7 business days
5	T2042119 Grip, APS, RH	Grip, APS, RH	1	$52.29	Backorder — Mid August 2026	1
6	T2044047 Sensor, AP	Sensor, AP	1	$212.87	Available to order	1 Ships within 3–7 business days
7	T2041629 Screw, APS Housing	Screw, APS Housing	2	$2.17	Available to order	2 Ships within 3–7 business days
8	T2028043 Bracket, Brake Switch, Front	Bracket, Brake Switch, Front	1	$12.94	Available to order	1 Ships within 3–7 business days
9	T2046673 Finisher, Bar End, Clear	Finisher, Bar End, Clear	2	$22.97	Available to order	2 Ships within 3–7 business days
10	T3330923 Screw, Csk, M6 x 20, Slv, Enc	Screw, Csk, M6 x 20, Slv, Enc	2	$2.37	Available to order	2 Ships within 3–7 business days
11	T2042144 Upper Yoke, Type C	Upper Yoke, Type C	1	$279.90	Available to order	1 Ships within 3–7 business days
12	T2042447 Upper Handlebar Clamp	Upper Handlebar Clamp	1	$59.73	Available to order	1 Ships within 3–7 business days
13	T3051097 Screw, Cap/Hd, M8 x 25, Silver	Screw, Cap/Hd, M8 x 25, Silver	6	$4.12	Available to order	6 Ships within 3–7 business days
14	T2042135 Nut, Upper, M25, Domed	Nut, Upper, M25, Domed	1	$3.77	Backorder — Mid August 2026	1
15	T3205765 Bolt, HHF, M10 x 65, Slv	Bolt, HHF, M10 x 65, Slv	2	$4.12	Available to order	2 Ships within 3–7 business days
16	T3700448 Cable Guide	Cable Guide	2	$4.19	Available to order	2 Ships within 3–7 business days
17	T2042136 Rubber Bush, Handlebar Clamp	Rubber Bush, Handlebar Clamp	4	$8.25	Available to order	4 Ships within 3–7 business days
18	T2049488 Sleeve, Dia 13 x 43	Sleeve, Dia 13 x 43	2	$4.86	Backorder — Early August 2026	2
19	T3550632 Washer, 10.5 x 21 x 2	Washer, 10.5 x 21 x 2	2	$2.95	Available to order	2 Ships within 3–7 business days
20	T2042448 Lower Handlebar Clamp, RHS	Lower Handlebar Clamp, RHS	1	$44.27	Available to order	1 Ships within 3–7 business days
21	T2042449 Lower Handlebar Clamp, LHS	Lower Handlebar Clamp, LHS	1	$44.27	Backorder — Early August 2026	1
23	T2060137 Mirror Assy, Brushed, LH	Mirror Assy, Brushed, LH	1	$139.05	Available to order	1 Ships within 3–7 business days
24	T2060138 Mirror Assy, Brushed, RH	Mirror Assy, Brushed, RH	1	$139.05	Available to order	1 Ships within 3–7 business days
25	T3331750 Screw, Tx, M4 x 17.5, Slv	Screw, Tx, M4 x 17.5, Slv	2	$4.30	Available to order	2 Ships within 3–7 business days
26	T3700212 Band, Rubber	Band, Rubber RH Switchcube	1	$3.29	Available to order	1 Ships within 3–7 business days
27	T2048021 Cover, Plastic	Cover, Plastic	1	$9.02	Available to order	1 Ships within 3–7 business days
28	T3700259 Rubber Band, 43mm	Rubber Band, 43mm LH Switchcube	1	$3.90	Available to order	1 Ships within 3–7 business days
29	T3331790 Screw, Pan/Hd, Ph, M5 x 30, Blk	Screw, Pan/Hd, Ph, M5 x 30, Blk	2	$0.89	Available to order	2 Ships within 3–7 business days
30	T3331826 Screw, Pan/Hd, M4 x 20, Blk	Screw, Pan/Hd, M4 x 20, Blk	2	$1.13	Obsolete	View Details
31	T2042154 Mount, Instruments	Mount, Instruments	1	$40.87	Out of Stock	Notify Me
32	T3700281 Clip, Cable Guide	Clip, Cable Guide	1	$3.17	Out of Stock	Notify Me
33	T3331042 Screw, Pan/Hd, Tx, M6 x 12, Enc	Screw, Pan/Hd, Tx, M6 x 12, Enc	2	$1.40	Available to order	2 Ships within 3–7 business days
