Loading schematic...
Gasket Kit, Full
Parts (47)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T3990141 Gasket Kit, Full | Gasket Kit, Full COMPRISES FOLLOWING PARTS: | 1 | $580.02 | Out of Stock | Notify Me |
| T1156029 Gasket, Cylinder Head, 97.6 | Gasket, Cylinder Head, 97.6 Cylinder Head Section | 1 | $99.47 | Available to order | 1 | |
| T1130710 Oil Seal, Valve Stem, 5mm | Oil Seal, Valve Stem, 5mm Cylinder Head Section | 8 | $10.66 | Available to order | 8 | |
| T3601276 O Ring, ID 23.7 x 2.9 | O Ring, ID 23.7 x 2.9 Camshaft/Cam Drive Section | 1 | $2.98 | Available to order | 1 | |
| T3600199 O Ring, 18.8 x Dia 1.9 | O Ring, 18.8 x Dia 1.9 Camshaft/Cam Drive Section | 1 | $1.47 | Available to order | 1 | |
| T3600163 O Ring, ID 19 x 3 | O Ring, ID 19 x 3 Balancer Section | 2 | $12.61 | Available to order | 2 | |
| T3600191 O Ring, 16 x 2 | O Ring, 16 x 2 Balancer Section | 2 | $3.77 | Available to order | 2 | |
| T3600216 O Ring, ID 9.8 x 3 | O Ring, ID 9.8 x 3 Balancer Section | 4 | $2.69 | Available to order | 4 | |
| T1179999 Washer, C, Clutch | Washer, C, Clutch Clutch Section | 1 | $11.71 | Available to order | 1 | |
| T1186601 Tab Washer, Sprocket | Tab Washer, Sprocket Transmission Section | 1 | $27.87 | Available to order | 1 | |
| T3600113 Seal, Oil 35 x 62 x 5 | Seal, Oil 35 x 62 x 5 Transmission Section | 1 | $24.60 | Available to order | 1 | |
| T1167250 Base Gasket | Base Gasket Crankcase Section | 1 | $29.56 | Available to order | 1 | |
| T3600153 O Ring, 7.6 x 2.4 | O Ring, 7.6 x 2.4 Crankcase Section | 2 | $2.00 | Available to order | 2 | |
| T3600268 O Ring, ID 7, 52 x 3, 53 | O Ring, ID 7, 52 x 3, 53 Crankcase Section | 1 | $5.42 | Out of Stock | Notify Me | |
| T1162911 Gasket, Breather | Gasket, Breather Crankcase Section | 1 | $4.55 | Backorder — Mid August 2026 | 1 | |
| T3600028 O Ring, Filler Cap | O Ring, Filler Cap Crankcase Section | 1 | $1.40 | Available to order | 1 | |
| T3550560 Washer, CU, OD16.0, ID8.4, 1.0 | Washer, CU, OD16.0, ID8.4, 1.0 Crankcase Section | 1 | $2.37 | Available to order | 1 | |
| T3600950 O Ring, 23.47 x 2.62 | O Ring, 23.47 x 2.62 Crankcase Section | 1 | $3.24 | Available to order | 1 | |
| T1260309 Seal, Cam Cover, Screw, Twin Lip | Seal, Cam Cover, Screw, Twin Lip Cam Cover Section | 4 | $5.82 | Available to order | 4 | |
| T1266002 Seal, Cam Cover | Seal, Cam Cover Cam Cover Section | 1 | $29.81 | Backorder — Late July 2026 | 1 | |
| T1268765 Gasket, Alternator Cover | Gasket, Alternator Cover Engine Covers Section | 1 | $13.72 | Available to order | 1 | |
| T1269876 Gasket, Clutch Cover | Gasket, Clutch Cover Engine Covers Section | 1 | $16.43 | Available to order | 1 | |
| T3600088 Seal, Oil, 14 x 22 x 4.5 | Seal, Oil, 14 x 22 x 4.5 Engine Covers Section | 1 | $6.39 | Available to order | 1 | |
| T3600095 Dust Seal | Dust Seal Engine Covers Section | 1 | $2.25 | Available to order | 1 | |
| T1230444 Gasket, Sump | Gasket, Sump Sump Section | 1 | $12.63 | Available to order | 1 | |
| T3558989 Washer, Sealing, 14.4 x 23 x 3 | Washer, Sealing, 14.4 x 23 x 3 Sump Section - Part only available as multipack, T3551092 | 1 | $2.01 | Available to order | 1 | |
| T3600128 Seal, Oil, Strainer | Seal, Oil, Strainer Lubrication Section | 1 | $7.71 | Available to order | 1 | |
| T3600109 O Ring, ID 5.6 x 2.3 | O Ring, ID 5.6 x 2.3 Lubrication Section | 4 | $5.30 | Available to order | 4 | |
| T3600176 O Ring, 6.1 x 1.6 | O Ring, 6.1 x 1.6 Lubrication Section | 2 | $2.95 | Available to order | 2 | |
| T3600117 O Ring 17 x 3 | O Ring 17 x 3 Lubrication Section | 2 | $7.14 | Available to order | 2 | |
| T3550546 Washer, Cu, OD 16 x ID 10.2/ | Washer, Cu, OD 16 x ID 10.2/ Lubrication Section | 1 | $0.89 | Available to order | 1 | |
| T3600290 O Ring, 23.7 x 2 | O Ring, 23.7 x 2 Lubrication Section | 1 | $1.40 | Available to order | 1 | |
| T3600217 O Ring, 12.6 ID x 2.4 | O Ring, 12.6 ID x 2.4 Lubrication Section | 1 | $3.39 | Available to order | 1 | |
| T1241996 Intake Seal | Intake Seal Throttle Body Section | 3 | $6.94 | Available to order | 3 | |
| T1241966 O Ring, Injector, Lower | O Ring, Injector, Lower Throttle Body Section | 2 | $5.42 | Available to order | 2 | |
| T2201429 Gasket, Exhaust Header | Gasket, Exhaust Header Exhaust Section | 2 | $15.93 | Available to order | 2 | |
| T2202153 Gasket, Exhaust, D35 | Gasket, Exhaust, D35 Exhaust Section | 2 | $12.98 | Available to order | 2 | |
| T2202346 Gasket, Exhaust | Gasket, Exhaust Exhaust Section | 4 | $13.72 | Available to order | 4 | |
| T2201094 Gasket, Exhaust | Gasket, Exhaust Exhaust Section - N/A for this model | 2 | $15.12 | Available to order | 2 | |
| T2202804 Gasket, Exhaust, ID25.3, OD31.8 | Gasket, Exhaust, ID25.3, OD31.8 Exhaust Section | 2 | $23.64 | Available to order | 2 | |
| T2100201 Seal, Thermostat | Seal, Thermostat Cooling Section | 1 | $7.14 | Available to order | 1 | |
| T2101277 Sealing Ring, Coolant Manifold | Sealing Ring, Coolant Manifold Cooling Section | 1 | $14.66 | Available to order | 1 | |
| T3600124 O Ring, ID 21.5 x 3 | O Ring, ID 21.5 x 3 Cooling Section | 4 | $3.39 | Available to order | 4 | |
| T3020153 Grommet, 13 x 3 x 10 | Grommet, 13 x 3 x 10 Cooling Section | 3 | $1.91 | Available to order | 3 | |
| T3550571 Washer, Cu, OD 16 x ID 12.5 | Washer, Cu, OD 16 x ID 12.5 Ignition Section | 1 | $5.07 | Available to order | 1 | |
| T3600267 O Ring, ID 26.65 x Dia 2.62 | O Ring, ID 26.65 x Dia 2.62 Ignition Section | 2 | $1.51 | Available to order | 2 | |
| T3600115 O Ring | O Ring Starter Motor Section | 1 | $3.39 | Available to order | 1 |
