Exhaust System
Parts (26)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | TA591538 Muffler Assembly, Primary | Muffler Assembly, Primary All expt BR | 1 | $697.38 | Backorder — Late July 2026 | 1 |
| 1 | TA591498 Muffler Assembly, Primary | Muffler Assembly, Primary BR Only | 1 | $697.38 | Out of Stock | Notify Me |
| 2 | TA591319 Assembly, Muffler, Secondary | Assembly, Muffler, Secondary All Except US & BR | 1 | $585.81 | Backorder — Late July 2026 | 1 |
| 2 | TA591374 Assembly, Muffler, Secondary | Assembly, Muffler, Secondary US Only | 1 | $585.81 | Backorder — Early August 2026 | 1 |
| 2 | TA591336 Assembly, Muffler, Secondary | Assembly, Muffler, Secondary BR Only | 1 | $568.75 | Backorder — Early August 2026 | 1 |
| 3 | TA591205 Nut, Clip, M8 | Nut, Clip, M8 | 2 | $1.13 | Available to order | 2 |
| 4 | LAD00328 Bolt, Flanged, M8 x 1.25 | Bolt, Flanged, M8 x 1.25 | 2 | $1.13 | Available to order | 2 |
| 5 | JY591303 Grommet Shield Muffler | Grommet Shield Muffler | 1 | $0.46 | Available to order | 1 |
| 6 | PD591845 Oxygen Sensor | Oxygen Sensor | 2 | $198.84 | Out of Stock | Notify Me |
| 7 | TA591206 Gasket, Exhaust | Gasket, Exhaust | 1 | $10.86 | Available to order | 1 |
| 8 | TA591434 Nut, Domed Cap Flanged, M8 x 1.25 | Nut, Domed Cap Flanged, M8 x 1.25 | 2 | $0.60 | Backorder — Early August 2026 | 2 |
| 9 | TA181240 Collar | Collar | 1 | $3.17 | Available to order | 1 |
| 10 | DJ181065 Clip Nut M6 | Clip Nut M6 | 3 | $0.67 | Available to order | 3 |
| 11 | LBU00204 Screw, Btn Hd, M6 x 1 | Screw, Btn Hd, M6 x 1 | 2 | $1.69 | Available to order | 2 |
| 12 | TA591273 Shield Catalyst | Shield Catalyst | 1 | $42.18 | Out of Stock | Notify Me |
| 13 | TA591321 Shield Assembly lii | Shield Assembly lii | 1 | $42.18 | Out of Stock | Notify Me |
| 14 | TA591032 Clamp | Clamp | 1 | $15.25 | Available to order | 1 |
| 15 | JP591033 Gasket Muffler Secondary | Gasket Muffler Secondary | 1 | $9.22 | Backorder — Early August 2026 | 1 |
| 16 | KCGD0808 Nut Hex Flanged | Nut Hex Flanged | 1 | $0.46 | Available to order | 1 |
| 17 | JY591245 Collar | Collar | 2 | $3.83 | Available to order | 2 |
| 18 | JY591246 Damper Muffler | Damper Muffler | 1 | $0.79 | Available to order | 1 |
| 19 | LBU00233 Bolt, Flanged, M8 x 1.25 | Bolt, Flanged, M8 x 1.25 | 1 | $3.39 | Available to order | 1 |
| 20 | TA591092 Shield Muffler | Shield Muffler | 1 | $18.35 | Available to order | 1 |
| 21 | TA591094 End Cap Assembly | End Cap Assembly | 1 | $137.62 | Available to order | 1 |
| 22 | LBU00203 Screw, Btn Hd, M6 x 1 | Screw, Btn Hd, M6 x 1 | 5 | $1.47 | Available to order | 5 |
| 23 | JW591030 Grommet, Shield | Grommet, Shield | 1 | $0.56 | Out of Stock | Notify Me |
