Loading schematic...
Rear Suspension
Parts (28)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2050862 Kit, Swingarm Assy, ABS | Kit, Swingarm Assy, ABS > 671846 - ABS Version - Inc Bearings Etc - items 2, 3, 4, 5, 6, 16 & 1 x T2022333 | 1 | $1329.09 | Backorder — Early August 2026 | 1 |
| 1 | T2050864 Kit, Swingarm Assy, Non ABS | Kit, Swingarm Assy, Non ABS > 671846 - Non ABS Version - Inc Bearings Etc - items 2, 3, 4, 5, 6, 16 & 1 x T2022334 | 1 | $1311.48 | Out of Stock | Notify Me |
| 1 | T2051174 Swingarm Assembly | Swingarm Assembly 671487 > Inc Bearings Etc, Items 2, 3, 4, 5 & 6 | 1 | $1276.27 | Out of Stock | Notify Me |
| 2 | T3600044 Oil Seal, 35 25 4 | Oil Seal, 35 25 4 | 2 | $10.44 | Available to order | 2 |
| 3 | T3800014 Roller bearing | Roller bearing | 1 | $14.32 | Available to order | 1 |
| 4 | T2054089 Spacer, 22 x 17 x 212 | Spacer, 22 x 17 x 212 | 1 | $19.47 | Available to order | 1 |
| 5 | T3800506 Bearing, Ball, 17 x 35 x 10 | Bearing, Ball, 17 x 35 x 10 | 2 | $19.29 | Available to order | 2 |
| 6 | T3500204 Circlip, Int, 35 x 1.5 | Circlip, Int, 35 x 1.5 | 1 | $0.97 | Available to order | 1 |
| 7 | T2054088 Spindle, Swingarm | Spindle, Swingarm | 1 | $91.26 | Available to order | 1 |
| 8 | T2054255 Sleeve, Ground, 25 17 28.5 | Sleeve, Ground, 25 17 28.5 | 1 | $13.61 | Available to order | 1 |
| 9 | T2054063 Spacer, 25 x 17 x 8.5 | Spacer, 25 x 17 x 8.5 | 2 | $8.01 | Available to order | 2 |
| 10 | T3551240 Washer, M16 x 34 x 3 | Washer, M16 x 34 x 3 | 1 | $2.63 | Available to order | 1 |
| 11 | T3350533 Domenut, Locking, M16 x 1.5 | Domenut, Locking, M16 x 1.5 | 1 | $11.48 | Available to order | 1 |
| 12 | T2050567 Belt Adjuster, LH | Belt Adjuster, LH | 1 | $33.82 | Available to order | 1 |
| 13 | T2050568 Belt Adjuster, RH | Belt Adjuster, RH | 1 | $33.82 | Out of Stock | Notify Me |
| 14 | T3350203 Nut, M10 x 1.25, Flanged | Nut, M10 x 1.25, Flanged | 2 | $2.48 | Available to order | 2 |
| 15 | T3350302 Nut, M10, Slv | Nut, M10, Slv | 2 | $0.89 | Available to order | 2 |
| 16 | T2054016 Belt Guard, Upper, Black | Belt Guard, Upper, Black 671847 > | 1 | $88.41 | Out of Stock | Notify Me |
| 16 | T2053999 belt Guard Upper, Blk | belt Guard Upper, Blk 413099 > 671846 | 1 | $88.41 | Available to order | 1 |
| 17 | T2050301 Belt Guard Lower | Belt Guard Lower | 1 | $51.31 | Available to order | 1 |
| 18 | T3330848 Bolt, But/Hd, M6 x 21, Shld, Slv | Bolt, But/Hd, M6 x 21, Shld, Slv 451924 > | 2 | $5.88 | Available to order | 2 |
| 19 | T3203222 Bolt, HHF, M6 x 12, Slv | Bolt, HHF, M6 x 12, Slv > 481167 | 1 | $1.72 | Out of Stock | Notify Me |
| 19 | T3205063 Bolt, HHF, Lghtd, M6 x 16, Slv | Bolt, HHF, Lghtd, M6 x 16, Slv 481168 > | 1 | $3.50 | Available to order | 1 |
| 20 | T3330726 Screw, Btn/Hd, M6 x 12, Slv | Screw, Btn/Hd, M6 x 12, Slv | 1 | $4.42 | Available to order | 1 |
| 21 | T2050682 RSU, Black Spring | RSU, Black Spring | 2 | $756.97 | Out of Stock | Notify Me |
| 22 | T3050158 Screw, Cap/Hd, M8 x 20, Enc | Screw, Cap/Hd, M8 x 20, Enc | 4 | $4.74 | Available to order | 4 |
| 23 | T2056604 Finisher, RSU, Styled, Black | Finisher, RSU, Styled, Black | 4 | $51.31 | Available to order | 4 |
| 25 | T3700180 Plug, Hole, Plastic | Plug, Hole, Plastic | 1 | $2.55 | Available to order | 1 |
