Loading schematic...
Rear Wheel & Final Drive
Parts (30)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2015270 Kit, Wheel, Rear, 17 x 5.5 | Kit, Wheel, Rear, 17 x 5.5 > 307178 (kit includes 4 x bolt disc T2020990) | 1 | $1047.42 | Available to order | 1 |
| 1 | T2015260 Wheel, Rear, 17 x 5.5, Slv | Wheel, Rear, 17 x 5.5, Slv 307179 > 483575 | 1 | $1188.28 | Available to order | 1 |
| 1 | T2015420 Wheel, Rear, 17 x 5.5, Blk | Wheel, Rear, 17 x 5.5, Blk 483576 > | 1 | $1188.28 | Out of Stock | Notify Me |
| 2 | T2012223 Rubber Cush Drive | Rubber Cush Drive | 1 | $114.08 | Available to order | 1 |
| 3 | T2012272 Spacer, Stepped | Spacer, Stepped | 1 | $29.94 | Out of Stock | Notify Me |
| 4 | T2012270 Sprocket Carrier Assy, Slv | Sprocket Carrier Assy, Slv > 483575 - ** Part No Longer Available ** | 1 | $356.76 | Obsolete | View Details |
| 4 | T2012285 Sprocket Carrier Assy, Blk | Sprocket Carrier Assy, Blk 483576 > ** Part No Longer Available ** | 1 | $295.62 | Obsolete | View Details |
| 5 | T3800215 Bearing, Ball, 30 62 16 | Bearing, Ball, 30 62 16 | 1 | $32.03 | Available to order | 1 |
| 6 | T3500075 Circlip, Internal, Dia 65 | Circlip, Internal, Dia 65 | 1 | $3.17 | Available to order | 1 |
| 7 | T3600112 Oil seal | Oil seal | 1 | $11.32 | Available to order | 1 |
| 8 | T2012144 Stud, Sprocket Carrier | Stud, Sprocket Carrier | 5 | $7.62 | Available to order | 5 |
| 9 | T2012113 Ring | Ring | 1 | $43.13 | Available to order | 1 |
| 10 | T2012514 Sprocket | Sprocket | 1 | $53.84 | Available to order | 1 |
| 11 | T3350250 Locknut, Flanged, M10 | Locknut, Flanged, M10 | 5 | $4.16 | Available to order | 5 |
| 12 | T2012273 Spacer, Tube, 40 20 11.5 | Spacer, Tube, 40 20 11.5 | 1 | $30.54 | Available to order | 1 |
| 13 | T2059052 Block, Chain Adj, LH | Block, Chain Adj, LH | 1 | $43.64 | Available to order | 1 |
| 14 | T3555035 Washer, 19 x 34 x 3 | Washer, 19 x 34 x 3 | 1 | $1.27 | Available to order | 1 |
| 15 | T3350118 Locknut, Plain, M18 | Locknut, Plain, M18 | 1 | $11.56 | Backorder — Late July 2026 | 1 |
| 16 | T2059051 Block, Chain Adj, RH | Block, Chain Adj, RH | 1 | $43.64 | Available to order | 1 |
| 17 | T2012030 Spindle | Spindle * Part No Longer Available * | 1 | $42.04 | Obsolete | View Details |
| 18 | T2012105 Spacer, Top Hat | Spacer, Top Hat * Part No Longer Available * | 1 | $13.90 | Obsolete | View Details |
| 20 | T2015148 Connecting Link, 530 Chain | Connecting Link, 530 Chain | 1 | $16.43 | Available to order | 1 |
| 21 | T2015149 530 Chain, 114 L, Split | 530 Chain, 114 L, Split | 1 | $267.41 | Available to order | 1 |
| 22 | T2006615 Valve Assy, aluminium, 90, Slv | Valve Assy, aluminium, 90, Slv > 483575 | 1 | $16.04 | Available to order | 1 |
| 22 | T2006635 Valve Assy, Alum, 90, Black | Valve Assy, Alum, 90, Black 483576 > | 1 | $16.04 | Available to order | 1 |
| 23 | T3600701 Oil Seal, DC 28 47 7 | Oil Seal, DC 28 47 7 | 1 | $22.52 | Backorder — Early August 2026 | 1 |
| 24 | T3500402 Circlip, Int Dia 47 | Circlip, Int Dia 47 | 1 | $0.89 | Available to order | 1 |
| 25 | T3800703 Bearing, Ball, 20 47 14 | Bearing, Ball, 20 47 14 | 2 | $45.80 | Available to order | 2 |
| 26 | T2012100 Spacer, Internal | Spacer, Internal | 1 | $24.60 | Backorder — Early August 2026 | 1 |
| 27 | T2017200 Chain & Sprocket Kit, 114/44/18 | Chain & Sprocket Kit, 114/44/18 | 1 | $274.57 | Available to order | 1 |
