Main Frame & Fittings
Parts (36)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2070910 Frame kit | Frame kit All markets except US & South America | 1 | $2082.04 | Obsolete | View Details |
| 1 | T2070915 Frame kit | Frame kit US 49 States, SG & South America | 1 | $2082.04 | Obsolete | View Details |
| 1 | T2070920 Frame kit | Frame kit US CAL | 1 | $2082.04 | Obsolete | View Details |
| 1 | T2079016 Frame kit | Frame kit Canada | 1 | $2082.04 | Obsolete | View Details |
| 2 | T3800031 Bearing, 30x55x17, Taper Roll | Bearing, 30x55x17, Taper Roll | 1 | $32.55 | Available to order | 1 |
| 3 | 2070002-T0301 Bearing cup | Bearing cup | 1 | $28.34 | Available to order | 1 |
| 4 | T3800032 Bearing, 24x47x15, Taper Roll | Bearing, 24x47x15, Taper Roll » 43782 | 1 | $61.04 | Out of Stock | Notify Me |
| 4 | T3800055 Bearing | Bearing 43783 » | 1 | $54.11 | Available to order | 1 |
| 5 | T2140210 Adjuster Nut, Upper | Adjuster Nut, Upper | 1 | $3.39 | Available to order | 1 |
| 6 | 2040225-T0301 Adjuster nut | Adjuster nut PART NO LONGER AVAILABLE » 43782 Lower | 1 | $5.11 | Obsolete | View Details |
| 6 | T2040259 Cover, Headstock Assy | Cover, Headstock Assy 43783 » Lower | 1 | $24.33 | Out of Stock | Notify Me |
| 7 | T2040061 Washer Upper Yoke | Washer Upper Yoke | 1 | $7.14 | Available to order | 1 |
| 8 | T2040060 Nut | Nut | 1 | $24.83 | Out of Stock | Notify Me |
| 9 | 2070723-T0301 Bracket lamp | Bracket lamp | 1 | $16.40 | Obsolete | View Details |
| 10 | T3450009 Plug, M6 | Plug, M6 | 4 | $3.24 | Available to order | 4 |
| 11 | T3203222 Bolt, HHF, M6 x 12, Slv | Bolt, HHF, M6 x 12, Slv | 6 | $1.72 | Out of Stock | Notify Me |
| 12 | 3900072-T0301 Badge | Badge | 1 | $4.44 | Obsolete | View Details |
| 13 | 2071021-T0301 Finisher | Finisher Top | 2 | $16.45 | Obsolete | View Details |
| 14 | T2071031 Finisher | Finisher Bottom | 2 | $15.28 | Obsolete | View Details |
| 15 | T3050334 Screw, Cap/Hd, M6 x 20, Slv | Screw, Cap/Hd, M6 x 20, Slv M6 x 20mm | 2 | $1.51 | Available to order | 2 |
| 16 | 3050038-T0301 Capscrew | Capscrew M6 x 10mm | 6 | $0.28 | Obsolete | View Details |
| 17 | 3050039-T0301 Capscrew | Capscrew M6 x 8mm - PART NO LONGER AVAILABLE | 6 | $1.57 | Obsolete | View Details |
| 18 | T3351002 Nut, Captive, U-Type, M5, Slv | Nut, Captive, U-Type, M5, Slv | 6 | $2.37 | Backorder — Mid August 2026 | 6 |
| 19 | T3900169 Label, Frame modification | Label, Frame modification US | 1 | $4.55 | Available to order | 1 |
| 20 | T3930095 Label | Label Carb diagram US CAL | 1 | $9.47 | Obsolete | View Details |
| 21 | 3900005-T0301 Asbestos label | Asbestos label English | 1 | $5.30 | Out of Stock | Notify Me |
| 21 | 3904005-T0301 Asbestos label | Asbestos label Spanish | 1 | $6.84 | Obsolete | View Details |
| 21 | 3910005-T0301 Asbestos label | Asbestos label German | 1 | $6.84 | Obsolete | View Details |
| 21 | 3901005-T0301 Asbestos label | Asbestos label Dutch | 1 | $5.69 | Backorder — Late July 2026 | 1 |
| 21 | 3902005-T0301 Asbestos label | Asbestos label French | 1 | $6.84 | Obsolete | View Details |
| 21 | 3903005-T0301 Asbestos label | Asbestos label Italian | 1 | $6.84 | Obsolete | View Details |
| 21 | 3906005-T0301 Asbestos label | Asbestos label Japanese | 1 | $4.76 | Obsolete | View Details |
| 21 | 3907005-T0301 Asbestos label | Asbestos label Portuguese | 1 | $4.76 | Obsolete | View Details |
| 22 | T3900041 Label | Label ECE DE | 1 | $6.84 | Obsolete | View Details |
| 23 | 3900010-T0301 Label | Label » 16921 Oil & filter UK, NZ, AU, ZA, GR, CY, HK, MY, SE | 1 | $4.76 | Unavailable | 1 |
| 23 | T3900136 Label, Engine Oil | Label, Engine Oil » 16921 Oil & filter CH, DE | 1 | $2.85 | Available to order | 1 |
