Rear Brake Disc and Caliper
Parts (19)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2020540 Caliper Assy, Front, RH | Caliper Assy, Front, RH | 1 | $654.52 | Unavailable | View Details |
| 2 | T2020086 Pad, Spring, D Spec | Pad, Spring, D Spec | 1 | $10.34 | Available to order | 1 |
| 3 | T2020084 Pad Pin Set, D Spec | Pad Pin Set, D Spec | 1 | $15.95 | Available to order | 1 |
| 4 | T2020014 Bleed Screw | Bleed Screw | 1 | $15.27 | Available to order | 1 |
| 5 | T2020050 Piston Set | Piston Set | 1 | $119.76 | Available to order | 1 |
| 6 | T2020505 Seal Kit, 2 Piston Caliper | Seal Kit, 2 Piston Caliper | 1 | $57.03 | Available to order | 1 |
| 7 | T2020077 Brake Pad Set, x 2 Pads | Brake Pad Set, x 2 Pads | 1 | $69.11 | Available to order | 1 |
| 8 | T3200601 Bolt, HHF, M8 x 40, Slv | Bolt, HHF, M8 x 40, Slv | 2 | $3.04 | Available to order | 2 |
| 9 | T2023355 Disc, Rear, Dia 285 | Disc, Rear, Dia 285 | 1 | $249.48 | Available to order | 1 |
| 10 | T2029090 Spares Kit, Disc Bolts | Spares Kit, Disc Bolts 12 bolts in kit | 1 | $71.34 | Available to order | 1 |
| 11 | T3450200 Plug, Caphead, Chrome | Plug, Caphead, Chrome | 5 | $4.19 | Available to order | 5 |
| 12 | T2020822 Brake carrier | Brake carrier | 1 | $153.08 | Obsolete | View Details |
| 13 | 2020803-T0301 Sleeve | Sleeve | 1 | $23.58 | Out of Stock | Notify Me |
| 14 | T2020943 Torque arm | Torque arm | 1 | $49.16 | Obsolete | View Details |
| 15 | T3050084 Bolt | Bolt M8 x 35mm | 1 | $1.83 | Obsolete | View Details |
| 16 | T3010275 Flanged sleeve | Flanged sleeve | 1 | $3.55 | Obsolete | View Details |
| 17 | T3350135 Nut | Nut | 1 | $8.33 | Available to order | 1 |
| 18 | T3330730 Bolt | Bolt | 1 | $25.01 | Obsolete | View Details |
| 19 | T3350134 Locknut, M10 x 1.25 | Locknut, M10 x 1.25 | 1 | $2.54 | Available to order | 1 |
