Loading schematic...
Rear Light
Parts (22)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2702020 Rear Light Bracket | Rear Light Bracket | 1 | $47.50 | Available to order | 1 |
| 2 | T3010707 Sleeve, Flanged, 6.4 x 10 x 6.5 | Sleeve, Flanged, 6.4 x 10 x 6.5 | 3 | $3.59 | Available to order | 3 |
| 3 | T3020082 Grommet, 18 x 1 x 9 | Grommet, 18 x 1 x 9 | 3 | $6.77 | Available to order | 3 |
| 4 | T3555026 Washer, 6.4 x 18 x 1.6 | Washer, 6.4 x 18 x 1.6 | 3 | $1.21 | Available to order | 3 |
| 5 | T3205085 Bolt, HHF, Lghtd, M6 x 20, Enc | Bolt, HHF, Lghtd, M6 x 20, Enc | 3 | $5.69 | Available to order | 3 |
| 6 | T3020158 Grommet, 13 x 3 x 9 | Grommet, 13 x 3 x 9 | 1 | $2.85 | Out of Stock | Notify Me |
| 7 | T3014444 Flanged Sleeve, 6.4 x 8.8 x 16 | Flanged Sleeve, 6.4 x 8.8 x 16 | 1 | $8.46 | Available to order | 1 |
| 8 | T3330739 Screw, But/Hd, M6 x 1 x 30, Slv | Screw, But/Hd, M6 x 1 x 30, Slv | 1 | $5.42 | Available to order | 1 |
| 9 | T3350003 Locknut, Flanged, M6 x 1 | Locknut, Flanged, M6 x 1 | 1 | $0.67 | Available to order | 1 |
| 10 | T2703790 Rear Light, Assembly | Rear Light, Assembly | 1 | $189.67 | Backorder — Late August 2026 | 1 |
| 11 | T2702017 Gasket, Cover Panel, Rear Light | Gasket, Cover Panel, Rear Light | 1 | $8.18 | Available to order | 1 |
| 12 | T3331436 Screw, S/Tap, Pan, Torx, 4 x 11, PT | Screw, S/Tap, Pan, Torx, 4 x 11, PT | 5 | $0.75 | Available to order | 5 |
| 13 | T2702015 Cover Panel, Rear Light | Cover Panel, Rear Light | 1 | $15.27 | Available to order | 1 |
| 14 | T3350161 Nut, Captive, M5 | Nut, Captive, M5 | 1 | $4.55 | Backorder — Late August 2026 | 1 |
| 15 | T2702014 Wire Guide, Rear Light | Wire Guide, Rear Light | 1 | $5.02 | Available to order | 1 |
| 16 | T3334511 Screw, Lge Skt Hd, M5 x 16, S/S | Screw, Lge Skt Hd, M5 x 16, S/S | 1 | $6.23 | Available to order | 1 |
| 17 | T2700443 Reflector, Oval, Red | Reflector, Oval, Red US, CA, AR, ZA, ID, KR Only | 2 | $6.14 | Available to order | 2 |
| 18 | T2700378 Reflector, Red, Circular | Reflector, Red, Circular | 1 | $9.10 | Available to order | 1 |
| 19 | T2702030 Bracket, Rear Reflector, Short | Bracket, Rear Reflector, Short AU, US, CA, JP, ID, NZ Only | 1 | $23.69 | Out of Stock | Notify Me |
| 19 | T2702021 Bracket, Rear Reflector, Long | Bracket, Rear Reflector, Long All Expt AU, US, CA, JP, ID, NZ | 1 | $25.00 | Available to order | 1 |
| 20 | T2701536 Bracket, Reflector, RH | Bracket, Reflector, RH | 1 | $5.46 | Available to order | 1 |
| 21 | T2701538 Bracket, Reflector, LH | Bracket, Reflector, LH | 1 | $5.46 | Out of Stock | Notify Me |
