Loading schematic...
Engine Covers
Parts (28)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T1269973 Kit, Sprocket Cover Assy | Kit, Sprocket Cover Assy | 1 | $121.69 | Out of Stock | Notify Me |
| 2 | T3205063 Bolt, HHF, Lghtd, M6 x 16, Slv | Bolt, HHF, Lghtd, M6 x 16, Slv | 4 | $3.50 | Available to order | 4 |
| 3 | T1170683 Lifter Arm, Clutch | Lifter Arm, Clutch | 1 | $98.85 | Available to order | 1 |
| 5 | T1170234 Return Spring | Return Spring | 1 | $5.88 | Available to order | 1 |
| 6 | T3555014 Washer, 13 x 18 x 1 | Washer, 13 x 18 x 1 | 1 | $1.27 | Backorder — Mid August 2026 | 1 |
| 7 | T1171990 Holder, Clutch Cable | Holder, Clutch Cable | 1 | $7.71 | Available to order | 1 |
| 8 | T1269050 Kit, Clutch Cover | Kit, Clutch Cover > Eng No 640260 | 1 | $329.18 | Out of Stock | Notify Me |
| 8 | T1261757 Clutch Cover Assy, Black | Clutch Cover Assy, Black Eng No 640261 > (includes logo) | 1 | $306.32 | Available to order | 1 |
| 9 | T1261097 Gasket, Clutch Cover | Gasket, Clutch Cover | 1 | $11.16 | Available to order | 1 |
| 10 | T3000005 Dowel, Dia 6 x 16.5 | Dowel, Dia 6 x 16.5 | 10 | $1.13 | Available to order | 10 |
| 11 | T3205083 Bolt, HHF, LGHTD, M6 x 28, Slv | Bolt, HHF, LGHTD, M6 x 28, Slv | 14 | $2.48 | Available to order | 14 |
| 12 | T1261180 Oil Filler Cap & Dipstick | Oil Filler Cap & Dipstick > Eng No 640260 **See Service Bulletin 503** | 1 | $17.37 | Available to order | 1 |
| 12 | T1261418 Dipstick Assy | Dipstick Assy Eng No 640261 > **See Service Bulletin 503** | 1 | $25.38 | Available to order | 1 |
| 14 | T1260808 Alternator Cover | Alternator Cover | 1 | $180.61 | Available to order | 1 |
| 15 | T3205067 Bolt, HHF, Lghtd, M6 x 25, Slv | Bolt, HHF, Lghtd, M6 x 25, Slv | 31 | $2.46 | Available to order | 31 |
| 16 | T1261098 Gasket, Alternator Cover | Gasket, Alternator Cover | 1 | $18.44 | Available to order | 1 |
| 17 | T1261217 Plate, Wire Retainer | Plate, Wire Retainer | 1 | $3.90 | Backorder — Early August 2026 | 1 |
| 18 | T3051055 Screw, Cap/Hd, M5 x 10, Slv, Enc | Screw, Cap/Hd, M5 x 10, Slv, Enc | 1 | $3.04 | Available to order | 1 |
| 19 | T1266621 Crank Cover, Black | Crank Cover, Black | 1 | $220.55 | Available to order | 1 |
| 20 | T1261103 Gasket, Crank Cover | Gasket, Crank Cover | 1 | $17.79 | Available to order | 1 |
| 21 | T1265432 Starter Cover, Black | Starter Cover, Black | 1 | $184.39 | Available to order | 1 |
| 22 | T1269999 Gasket, Starter Cover | Gasket, Starter Cover | 1 | $17.79 | Backorder — Late August 2026 | 1 |
| 23 | T3700157 Clip, Cable Guide | Clip, Cable Guide | 1 | $3.17 | Available to order | 1 |
| 24 | T1261223 Plug, M45 x 1.25, Black | Plug, M45 x 1.25, Black | 1 | $33.47 | Available to order | 1 |
| 25 | T3600222 O ring | O ring | 1 | $11.55 | Available to order | 1 |
| 27 | T3600095 Dust Seal | Dust Seal | 1 | $2.25 | Available to order | 1 |
| 28 | T3331109 Bolt, HHF, M6 x 28, SS, Enc | Bolt, HHF, M6 x 28, SS, Enc | 1 | $2.25 | Available to order | 1 |
| 30 | T3020059 Grommet, Bodywork | Grommet, Bodywork | 1 | $2.55 | Available to order | 1 |
