Loading schematic...
Crankcase & Fittings
Parts (25)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T1162043 Crankcase Assy, Spares | Crankcase Assy, Spares > Eng No 941631 | 1 | $5093.16 | Backorder — Late July 2026 | 1 |
| 1 | T1162210 Crankcase Assy, Spares | Crankcase Assy, Spares Eng No 941632 > | 1 | $5093.16 | Out of Stock | Notify Me |
| 2 | T3000103 Dowel, Hollow, 12 x 14 | Dowel, Hollow, 12 x 14 | 6 | $4.08 | Available to order | 6 |
| 3 | T3450091 Plug, Dia 14, Alum | Plug, Dia 14, Alum | 3 | $2.48 | Out of Stock | Notify Me |
| 4 | T1180025 Retainer, Bearing, Pressing | Retainer, Bearing, Pressing | 1 | $1.72 | Available to order | 1 |
| 5 | T3051062 Screw, M6 x 12, Enc, Raw | Screw, M6 x 12, Enc, Raw | 2 | $1.47 | Available to order | 2 |
| 6 | T1160268 Spigot, OD 14.0mm | Spigot, OD 14.0mm | 1 | $5.78 | Available to order | 1 |
| 7 | T3802512 Bearing, Needle | Bearing, Needle | 1 | $11.22 | Available to order | 1 |
| 8 | T1160751 Main Bearing Shell, Grooved | Main Bearing Shell, Grooved Red | 8 | $12.70 | Available to order | 8 |
| 8 | T1160752 Main Bearing Shell, Grooved | Main Bearing Shell, Grooved Blue | 8 | $12.70 | Available to order | 8 |
| 8 | T1160753 Main Bearing Shell, Grooved | Main Bearing Shell, Grooved Green | 8 | $12.70 | Available to order | 8 |
| 9 | T3600812 O ring | O ring | 1 | $1.51 | Available to order | 1 |
| 10 | T3205062 Bolt, HHF, Lghtd, M6 x 12, Slv | Bolt, HHF, Lghtd, M6 x 12, Slv | 1 | $4.19 | Available to order | 1 |
| 11 | T3550542 Washer, Cu, OD12.5 x Id6.4 | Washer, Cu, OD12.5 x Id6.4 | 1 | $1.05 | Available to order | 1 |
| 12 | T3000101 Dowel, Hollow, 8 x 14 | Dowel, Hollow, 8 x 14 | 2 | $3.90 | Backorder — Late August 2026 | 2 |
| 13 | T3500208 Circlip, Int, 32 x 2 | Circlip, Int, 32 x 2 | 1 | $0.97 | Available to order | 1 |
| 14 | T1161065 Plate, Assy, Breather | Plate, Assy, Breather | 1 | $12.29 | Out of Stock | Notify Me |
| 15 | T3331990 Bolt, But/Hd, M6 x 12, Slv, Enc | Bolt, But/Hd, M6 x 12, Slv, Enc | 7 | $1.40 | Available to order | 7 |
| 16 | T1160262 Hose, Breather Drain | Hose, Breather Drain | 1 | $5.14 | Available to order | 1 |
| 17 | T3700035 Clip, Hose, Dia 13.5-15.0 | Clip, Hose, Dia 13.5-15.0 | 1 | $0.75 | Available to order | 1 |
| 18 | T1161066 Gasket, Breather Plate | Gasket, Breather Plate | 1 | $9.31 | Available to order | 1 |
| 19 | T1211050 Oil Feed Assy, Gearbox | Oil Feed Assy, Gearbox | 1 | $53.24 | Out of Stock | Notify Me |
| 20 | T1210242 Bolt, Banjo, M6 x 20 | Bolt, Banjo, M6 x 20 | 3 | $11.03 | Backorder — Late August 2026 | 3 |
| 22 | T3100040 Stud, M6 x 35, Enc | Stud, M6 x 35, Enc | 1 | $2.10 | Out of Stock | Notify Me |
| 23 | T3455016 Sealing Plug, Int Hex, M16 x 1.5 | Sealing Plug, Int Hex, M16 x 1.5 Eng No 941632 > | 1 | $8.07 | Out of Stock | Notify Me |
