Engine Covers
Parts (23)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T1261311 Sprocket Cover Assembly | Sprocket Cover Assembly | 1 | $110.28 | Out of Stock | Notify Me |
| 2 | T3205063 Bolt, HHF, Lghtd, M6 x 16, Slv | Bolt, HHF, Lghtd, M6 x 16, Slv | 4 | $3.50 | Available to order | 4 |
| 3 | T1261760 Clutch Cover Assy, Painted | Clutch Cover Assy, Painted | 1 | $306.32 | Available to order | 1 |
| 4 | T1261097 Gasket, Clutch Cover | Gasket, Clutch Cover | 1 | $11.16 | Available to order | 1 |
| 5 | T3000005 Dowel, Dia 6 x 16.5 | Dowel, Dia 6 x 16.5 | 8 | $1.13 | Available to order | 8 |
| 6 | T3205083 Bolt, HHF, LGHTD, M6 x 28, Slv | Bolt, HHF, LGHTD, M6 x 28, Slv | 14 | $2.48 | Available to order | 14 |
| 7 | T1261418 Dipstick Assy | Dipstick Assy | 1 | $25.38 | Available to order | 1 |
| 8 | T3600163 O Ring, ID 19 x 3 | O Ring, ID 19 x 3 | 1 | $12.61 | Available to order | 1 |
| 9 | T1261711 Alternator Cover | Alternator Cover | 1 | $178.72 | Out of Stock | Notify Me |
| 10 | T3205067 Bolt, HHF, Lghtd, M6 x 25, Slv | Bolt, HHF, Lghtd, M6 x 25, Slv | 30 | $2.46 | Available to order | 30 |
| 11 | T1261098 Gasket, Alternator Cover | Gasket, Alternator Cover | 1 | $18.44 | Available to order | 1 |
| 12 | T1261190 Plate, Wire Retainer | Plate, Wire Retainer | 1 | $5.24 | Available to order | 1 |
| 13 | T3051055 Screw, Cap/Hd, M5 x 10, Slv, Enc | Screw, Cap/Hd, M5 x 10, Slv, Enc | 1 | $3.04 | Available to order | 1 |
| 14 | T1262203 Crank Cover, Black | Crank Cover, Black | 1 | $220.55 | Available to order | 1 |
| 15 | T1261103 Gasket, Crank Cover | Gasket, Crank Cover | 1 | $17.79 | Available to order | 1 |
| 16 | T1266008 Starter Cover, Black | Starter Cover, Black | 1 | $178.72 | Available to order | 1 |
| 17 | T1269999 Gasket, Starter Cover | Gasket, Starter Cover | 1 | $17.79 | Backorder — Late August 2026 | 1 |
| 18 | T1261226 Plug, M45 x 1.25, Black | Plug, M45 x 1.25, Black | 1 | $16.42 | Backorder — Mid August 2026 | 1 |
| 19 | T3600222 O ring | O ring | 1 | $11.55 | Available to order | 1 |
| 20 | T3600095 Dust Seal | Dust Seal | 1 | $2.25 | Available to order | 1 |
| 21 | T3951060 Badge, Flat, Type 1 | Badge, Flat, Type 1 | 2 | $13.33 | Available to order | 2 |
| 22 | T3700157 Clip, Cable Guide | Clip, Cable Guide | 1 | $3.17 | Available to order | 1 |
| 23 | T3205081 Bolt, HHF, Lghtd, M6 x 28, Enc | Bolt, HHF, Lghtd, M6 x 28, Enc | 1 | $1.51 | Out of Stock | Notify Me |
