Rear Suspension Linkage
Parts (12)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2057306 Draglink, Cast Aluminium | Draglink, Cast Aluminium | 1 | $38.68 | Available to order | 1 |
| 2 | T2057323 Droplink Plates, Black | Droplink Plates, Black | 2 | $51.31 | Available to order | 2 |
| 3 | T2057399 Sleeve, Ground Steel, 90mm | Sleeve, Ground Steel, 90mm | 1 | $40.22 | Available to order | 1 |
| 4 | T2057401 Sleeve, Ground Steel, 26mm | Sleeve, Ground Steel, 26mm | 1 | $13.61 | Available to order | 1 |
| 5 | T3800199 Bearing, Needle Roller, 20 x 26 x 20 | Bearing, Needle Roller, 20 x 26 x 20 | 3 | $16.50 | Available to order | 3 |
| 6 | T3600178 Seal, 20 x 26 x 4 | Seal, 20 x 26 x 4 | 6 | $7.71 | Available to order | 6 |
| 7 | T3800060 Bearing, Needle Roller, 202620 | Bearing, Needle Roller, 202620 | 1 | $37.15 | Available to order | 1 |
| 8 | T2057354 Sleeve, Linkage, Dia 20.0 x 30.5 | Sleeve, Linkage, Dia 20.0 x 30.5 | 1 | $10.71 | Available to order | 1 |
| 9 | T3350234 Locknut, Flgd, M12 x 1.25 | Locknut, Flgd, M12 x 1.25 | 4 | $6.07 | Available to order | 4 |
| 10 | T3332125 Bolt, Tx, M12 x 56, Slv Replaced by T3334640 — Screw, HHF, M12 x 60 | Bolt, Tx, M12 x 56, Slv | 1 | $5.69 | Unavailable | View Details |
| 11 | T3334680 Bolt, HHF, M12 x 119, Slv | Bolt, HHF, M12 x 119, Slv | 2 | $8.33 | Available to order | 2 |
| 12 | T3150316 Bolt, HHF, M12 x 70, Silver | Bolt, HHF, M12 x 70, Silver | 1 | $13.10 | Available to order | 1 |
