Loading schematic...
Rear Swingarm
Parts (20)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2052508 Kit, Swingarm Spares Assembly | Kit, Swingarm Spares Assembly > 727558 - Includes items 7, 8 & 13 (+ T3800199 x 2) | 1 | $1496.30 | Available to order | 1 |
| 1 | T2051703 Swingarm Spares Assembly | Swingarm Spares Assembly 727559 > - Includes items 7 & 8 (+ T3800199 x 2) | 1 | $1452.32 | Out of Stock | Notify Me |
| 2 | T3330644 Screw, H/HD, M8 x 75, Slv | Screw, H/HD, M8 x 75, Slv | 2 | $1.27 | Available to order | 2 |
| 3 | T3350303 Nut, M8, Silver | Nut, M8, Silver | 2 | $0.81 | Available to order | 2 |
| 4 | T2057047 Chainguard, Moulded, Long | Chainguard, Moulded, Long | 1 | $70.35 | Available to order | 1 |
| 5 | T3332666 Screw, But/Hd ,Skt, M6 x 1.0 x 12, S/S | Screw, But/Hd ,Skt, M6 x 1.0 x 12, S/S | 3 | $4.30 | Available to order | 3 |
| 6 | T2050460 Spindle, Swingarm | Spindle, Swingarm | 1 | $100.76 | Available to order | 1 |
| 7 | T3600162 Oil Seal, 32 25 4 | Oil Seal, 32 25 4 | 4 | $8.53 | Available to order | 4 |
| 8 | T3800014 Roller bearing | Roller bearing | 2 | $14.32 | Available to order | 2 |
| 9 | T2052235 Sleeve, Ground | Sleeve, Ground | 2 | $22.98 | Available to order | 2 |
| 10 | T2054562 Bush, Moulded | Bush, Moulded | 2 | $8.01 | Available to order | 2 |
| 11 | T3350155 Locknut, Thin, M16 | Locknut, Thin, M16 | 1 | $9.41 | Available to order | 1 |
| 12 | T3551240 Washer, M16 x 34 x 3 | Washer, M16 x 34 x 3 | 1 | $2.63 | Available to order | 1 |
| 13 | T2051790 Rubbing Strip, Moulded | Rubbing Strip, Moulded > 745920 All Except BR/IN & > 746793 BR/IN Only | 1 | $45.25 | Available to order | 1 |
| 13 | T2051795 Rubbing Strip, Moulded | Rubbing Strip, Moulded 745921 > All Except BR/IN & 746794 > BR/IN Only | 1 | $66.72 | Available to order | 1 |
| 14 | T2051767 Damper, Rubbing Strip | Damper, Rubbing Strip | 2 | $45.25 | Available to order | 2 |
| 15 | T3330727 Screw, But/Hd, M6 x 20, Slv | Screw, But/Hd, M6 x 20, Slv | 1 | $3.39 | Available to order | 1 |
| 16 | T3010061 Flanged Sleeve, M6 x 9 x 3.25 | Flanged Sleeve, M6 x 9 x 3.25 | 1 | $7.22 | Available to order | 1 |
| 17 | T2051773 Lower Chainguard, Moulded | Lower Chainguard, Moulded | 1 | $70.35 | Available to order | 1 |
| 18 | T3202304 Bolt, RHHF, M6 x 20, Slv | Bolt, RHHF, M6 x 20, Slv | 2 | $5.30 | Available to order | 2 |
