Loading schematic...
Mounting Kit, Panniers > 732934
Parts (26)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | A9500603 Mounting Kit, Panniers | Mounting Kit, Panniers > 732934 | 1 | $385.00 | Obsolete | View Details |
| 2 | T2203434 Stop, Silencer | Stop, Silencer | 2 | $6.83 | Available to order | 2 |
| 3 | T3202315 Bolt, HHF, M8 x 65, Slv | Bolt, HHF, M8 x 65, Slv | 5 | $8.18 | Available to order | 5 |
| 4 | T3350004 Locknut, Flanged, M8 x 1.25 | Locknut, Flanged, M8 x 1.25 | 2 | $2.45 | Available to order | 2 |
| 6 | T3205064 Bolt, RHHF, Domed, S/S, M6 x 16, Enc | Bolt, RHHF, Domed, S/S, M6 x 16, Enc | 2 | $4.01 | Available to order | 2 |
| 7 | T3205254 Bolt, HHF, Lghtd, M8 x 20, Slv | Bolt, HHF, Lghtd, M8 x 20, Slv | 4 | $1.62 | Backorder — Early August 2026 | 4 |
| 9 | T2352361 Spacer, Pannier | Spacer, Pannier | 3 | $1.13 | Available to order | 3 |
| 11 | T2352350 Mounting Frame, Assy, RH | Mounting Frame, Assy, RH | 1 | $440.08 | Available to order | 1 |
| 12 | T2352360 Mounting Frame, Assy, LH | Mounting Frame, Assy, LH | 1 | $440.08 | Available to order | 1 |
| 13 | T2352370 Rear Link Bar | Rear Link Bar | 1 | $26.87 | Available to order | 1 |
| 14 | T2352355 Mounting Frame, Fabrication, RH | Mounting Frame, Fabrication, RH | 1 | $448.88 | Out of Stock | Notify Me |
| 15 | T2352365 Mounting Frame, Fabrication, LH | Mounting Frame, Fabrication, LH | 1 | $148.31 | Available to order | 1 |
| 16 | T2352353 Rear Body, Mechanism | Rear Body, Mechanism | 4 | $44.09 | Out of Stock | Notify Me |
| 17 | T2352354 Mechanism, Internal | Mechanism, Internal | 4 | $96.97 | Out of Stock | Notify Me |
| 18 | T2352356 Spring, Mechanism | Spring, Mechanism | 8 | $53.24 | Available to order | 8 |
| 19 | T2352357 Screw, Csk, M8 x 1.25 x 35 | Screw, Csk, M8 x 1.25 x 35 | 4 | $5.30 | Out of Stock | Notify Me |
| 20 | T2352358 Locknut, M8 x 1.25 | Locknut, M8 x 1.25 | 4 | $2.25 | Out of Stock | Notify Me |
| 21 | T2350203 Screw, Csk, M6 x 27, Enc | Screw, Csk, M6 x 27, Enc | 4 | $4.45 | Available to order | 4 |
| 22 | T2350208 Casting, Upper | Casting, Upper | 2 | $182.47 | Available to order | 2 |
| 23 | T9509542 Bobbin, Luggage | Bobbin, Luggage | 4 | $17.80 | Available to order | 4 |
| 24 | T2707111 Reflex Reflector | Reflex Reflector | 2 | $9.88 | Available to order | 2 |
| 25 | T3600109 O Ring, ID 5.6 x 2.3 | O Ring, ID 5.6 x 2.3 | 4 | $5.30 | Available to order | 4 |
| 26 | T3550253 Washer, Dia 5 mm, Retaining | Washer, Dia 5 mm, Retaining | 4 | $0.97 | Available to order | 4 |
| 27 | T9500561 Expanding Clamp, Pair | Expanding Clamp, Pair | 2 | $33.99 | Obsolete | View Details |
| 28 | T2201959 Finisher, Silencer, Black | Finisher, Silencer, Black | 1 | $247.17 | Available to order | 1 |
| 29 | T2350183 Protective Sticker Set | Protective Sticker Set | 1 | $6.94 | Out of Stock | Notify Me |
