LED Fog Light Kit
Schematic
Parts (14)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | A9838029 LED Fog Light Kit | LED Fog Light Kit Market Restrictions Apply - Does not include switch T2701581. Please order A9828031 instead if switch required | 1 | $320.00 | Obsolete | View Details |
| 2 | T2701465 Fog Lamp, LED | Fog Lamp, LED | 2 | $245.24 | Available to order | 2 |
| 6 | T3330649 Screw, Pan/Hd, Tx, M5 x 12, Slv | Screw, Pan/Hd, Tx, M5 x 12, Slv | 4 | $5.67 | Available to order | 4 |
| 7 | T3555050 Washer, 5.3 x 12.5mm | Washer, 5.3 x 12.5mm | 4 | $0.97 | Available to order | 4 |
| 8 | T3700015 Cable Tie, 185.7 Long | Cable Tie, 185.7 Long | 4 | $0.89 | Available to order | 4 |
| 9 | T3205067 Bolt, HHF, Lghtd, M6 x 25, Slv | Bolt, HHF, Lghtd, M6 x 25, Slv | 2 | $2.46 | Available to order | 2 |
| 10 | A9910361 Sleeve, Flgd, 6.4 x 15.0 x 5.5 | Sleeve, Flgd, 6.4 x 15.0 x 5.5 | 4 | $4.86 | Out of Stock | Notify Me |
| 11 | T3205063 Bolt, HHF, Lghtd, M6 x 16, Slv | Bolt, HHF, Lghtd, M6 x 16, Slv | 2 | $3.50 | Available to order | 2 |
| 12 | T3330941 Screw, But/Hd, Skt, M5 x 16, Slv | Screw, But/Hd, Skt, M5 x 16, Slv | 4 | $6.73 | Available to order | 4 |
| 13 | T3021250 Grommet, Dia 18x4 | Grommet, Dia 18x4 | 2 | $2.95 | Available to order | 2 |
| 14 | T2701580 Shroud, Fog Lamp, LH | Shroud, Fog Lamp, LH | 1 | $56.73 | Available to order | 1 |
| 15 | T2701585 Shroud, Fog Lamp, RH | Shroud, Fog Lamp, RH | 1 | $56.73 | Available to order | 1 |
| 16 | T2701802 Bracket, Fog Lamp, LH | Bracket, Fog Lamp, LH | 1 | $42.00 | Available to order | 1 |
| 17 | T2701803 Bracket, Fog Lamp, RH | Bracket, Fog Lamp, RH | 1 | $42.00 | Available to order | 1 |
