Gear Change Mechanism
Parts (20)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2088000 Gearchange Assembly | Gearchange Assembly | 1 | $180.61 | Available to order | 1 |
| 2 | T2082882 Gearchange Rod | Gearchange Rod | 1 | $30.82 | Out of Stock | Notify Me |
| 3 | T3350300 Nut, M6 x 1.0, Slv | Nut, M6 x 1.0, Slv | 1 | $0.94 | Available to order | 1 |
| 4 | T3350304 Nut, LH, M6, Slv | Nut, LH, M6, Slv | 1 | $1.51 | Available to order | 1 |
| 5 | T2088004 Clamp Assy, Linkage | Clamp Assy, Linkage | 1 | $112.13 | Available to order | 1 |
| 6 | T3205066 Bolt, HHF, Lghtd, M6 x 20, Slv | Bolt, HHF, Lghtd, M6 x 20, Slv | 1 | $4.55 | Available to order | 1 |
| 7 | T3331614 Bolt, Shld, M8, Slv Enc | Bolt, Shld, M8, Slv Enc | 1 | $10.06 | Available to order | 1 |
| 8 | T1199106 Gearchange Shaft Assembly | Gearchange Shaft Assembly | 1 | $214.49 | Available to order | 1 |
| 10 | T3502535 Circlip, Din 471, Dia. 14.0 | Circlip, Din 471, Dia. 14.0 | 2 | $1.91 | Available to order | 2 |
| 11 | T3550236 Washer, 14 x 20 x 1.6 | Washer, 14 x 20 x 1.6 | 2 | $2.95 | Available to order | 2 |
| 12 | T1193333 Spring, Gearchange, Return | Spring, Gearchange, Return | 1 | $4.74 | Available to order | 1 |
| 13 | T1194900 Pivot Plate | Pivot Plate | 1 | $46.84 | Backorder — Early August 2026 | 1 |
| 14 | T1190123 Spring, Pivot Plate | Spring, Pivot Plate | 1 | $13.01 | Out of Stock | Notify Me |
| 15 | T3555003 Washer, 12 x 18 x 1.2 | Washer, 12 x 18 x 1.2 | 1 | $1.40 | Available to order | 1 |
| 16 | T3500068 Circlip, Din 471, Dia 12 | Circlip, Din 471, Dia 12 | 1 | $1.91 | Available to order | 1 |
| 17 | T3550444 Washer, 15.5 x 25 | Washer, 15.5 x 25 | 1 | $1.78 | Available to order | 1 |
| 18 | T3550090 Washer, Thrust | Washer, Thrust | 1 | $4.12 | Available to order | 1 |
| 19 | T3500044 E Circlip | E Circlip | 1 | $0.97 | Available to order | 1 |
| 20 | T1190003 Pin, Spring Abutment | Pin, Spring Abutment | 1 | $18.57 | Backorder — Late July 2026 | 1 |
| 21 | T2080766 Rubber, Gearchange Pedal | Rubber, Gearchange Pedal | 1 | $9.22 | Available to order | 1 |
