Triumph Adventurer Bodywork — OEM Parts Diagram

Engle Motors is your source for OEM Triumph parts and accessories with free shipping on orders of $100+!OEM Triumph parts — free shipping over $100!

Loading schematic...

What Our Customers Say

5 out of 5 based on 710 reviews

View all reviews →

“I like the procedure of verifying the part # with my motorcycle VIN#.”

M. Armfield · LOS ALTOS, CA · Mar 2026

“It would be nice to have better drawings of the parts. These were fuzzy and difficult to make out.”

M. Cohen · Pasadena, CA · Mar 2026

“EASY TO USE WEBSITE, AND GREAT SERVICE!”

J. SHEETS · CINCINNATI, OH · Feb 2026

“You guys are awesome! I Always use you guys for parts! Your diagrams are easy to move through. I will say the cooling system side was a little hard to figure out but praise be that theres a search bar! All n' all, 10/10! Rock on!”

N. Drinkall · BUHL, ID · Feb 2026

“Very efficient process... no hoping on a smooth delivery process. :-)”

P. De Keersmaecker · JACKSONVILLE, FL · Feb 2026

“Thank you, search was easy and glad I found you guys.”

P. Melia · SAINT PETERSBURG, FL · Feb 2026

#	Part Number	Description	Qty	Price	Status
1	T2303420-PC Side panel lh	Side panel lh Black	1	$199.56	Obsolete	View Details
1	T2303420-KE Side panel lh	Side panel lh Violet	1	$199.56	Obsolete	View Details
1	T2303420-GC Side panel lh	Side panel lh Gold	1	$199.56	Obsolete	View Details
1	T2303420-EC Side panel lh	Side panel lh Amber	1	$199.56	Obsolete	View Details
1	T2303420-JK Side panel lh	Side panel lh Turquoise	1	$199.56	Obsolete	View Details
1	T2303420-TC Side panel lh	Side panel lh Aubergine	1	$199.56	Obsolete	View Details
1	T2303420-PG Side panel lh	Side panel lh Jet Black	1	$190.06	Obsolete	View Details
2	T2303422-PC Side panel rh	Side panel rh Black	1	$212.51	Obsolete	View Details
2	T2303422-KE Side panel rh	Side panel rh Violet	1	$212.51	Obsolete	View Details
2	T2303422-GC Side panel rh	Side panel rh Gold	1	$212.51	Obsolete	View Details
2	T2303422-EC Side panel rh	Side panel rh Amber	1	$212.51	Obsolete	View Details
2	T2303422-JK Side panel rh	Side panel rh Turquoise	1	$212.51	Obsolete	View Details
2	T2303422-TC Side panel rh	Side panel rh Aubergine	1	$212.51	Obsolete	View Details
2	T2303422-PG Side panel rh	Side panel rh Jet Black	1	$190.06	Obsolete	View Details
3	T3900068 Badge	Badge	2	$50.50	Obsolete	View Details
4	T3350010 Locknut, Flgd, M5	Locknut, Flgd, M5 M5	4	$2.25	Available to order	4 Ships within 3–7 business days
5	T3660138 Seal, Seat Lock, 0.9mm	Seal, Seat Lock, 0.9mm	1	$1.51	Available to order	1 Ships within 3–7 business days
6	T3020121 Grommet, 13 x 1 x 6.2	Grommet, 13 x 1 x 6.2	4	$2.00	Available to order	4 Ships within 3–7 business days
7	T3020082 Grommet, 18 x 1 x 9	Grommet, 18 x 1 x 9	2	$6.77	Available to order	2 Ships within 3–7 business days
8	T3010707 Sleeve, Flanged, 6.4 x 10 x 6.5	Sleeve, Flanged, 6.4 x 10 x 6.5	2	$3.59	Available to order	2 Ships within 3–7 business days
9	T3330727 Screw, But/Hd, M6 x 20, Slv	Screw, But/Hd, M6 x 20, Slv	2	$3.39	Available to order	2 Ships within 3–7 business days
10	T2201389 Airbox Cover, LH, Chromed, RT	Airbox Cover, LH, Chromed, RT	1	$136.95	Obsolete	View Details
11	T2201388 Airbox Cover, RH, Chromed, RT	Airbox Cover, RH, Chromed, RT	1	$136.95	Obsolete	View Details
12	T3900083 Badge	Badge	2	$27.78	Obsolete	View Details
13	T3330550 Screw M6 x 16, S/S, Large HD	Screw M6 x 16, S/S, Large HD M6 x 12mm - * PART NO LONGER AVAILABLE *	4	$3.23	Obsolete	View Details
