Loading schematic...
Clutch
Parts (25)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T1170142 Clutch Assy, Spares, Shimmed Replaced by T1177142 — Clutch Assy, Spares, Shimmed | Clutch Assy, Spares, Shimmed | 1 | $792.77 | Unavailable | View Details |
| 2 | T1170460 Clutch Outer, Spares, Shimmed | Clutch Outer, Spares, Shimmed | 1 | $800.95 | Available to order | 1 |
| 3 | T1170258 Spares Kit, Clutch | Spares Kit, Clutch Kit Contains - Clutch Centre, Pressure Plate & Lifter | 1 | $536.92 | Available to order | 1 |
| 4 | T1170506 Plate, Clutch, 2.0 mm | Plate, Clutch, 2.0 mm | 7 | $28.41 | Available to order | 7 |
| 4 | T1170516 Plate, Clutch, 1.6 mm | Plate, Clutch, 1.6 mm | — | $38.56 | Available to order | 1 |
| 4 | T1170526 Plate, Clutch, 2.3 mm | Plate, Clutch, 2.3 mm | — | $38.56 | Available to order | 1 |
| 5 | T1170157 Plate B, Clutch | Plate B, Clutch | 1 | $68.42 | Out of Stock | Notify Me |
| 6 | T1172613 Spares Kit, Friction Disks | Spares Kit, Friction Disks | 1 | $226.12 | Out of Stock | Notify Me |
| 7 | T1170052 Disc A, Clutch Friction | Disc A, Clutch Friction | 6 | $29.97 | Available to order | 6 |
| 8 | T1170156 Disk B, Cltuch Friction | Disk B, Cltuch Friction | 3 | $46.64 | Available to order | 3 |
| 10 | T1174700 Washer, 25.5 x 53 x 2 | Washer, 25.5 x 53 x 2 | 1 | $10.18 | Available to order | 1 |
| 12 | T1170168 Spring, Judder | Spring, Judder | 1 | $29.24 | Out of Stock | Notify Me |
| 13 | T1170024 Seat, Judder Spring | Seat, Judder Spring | 1 | $12.63 | Available to order | 1 |
| 15 | T1170804 Bolt, Hex Head, M6 x 50 | Bolt, Hex Head, M6 x 50 | 3 | $2.25 | Available to order | 3 |
| 16 | T1170153 Seat, Clutch Spring | Seat, Clutch Spring | 3 | $8.18 | Available to order | 3 |
| 17 | T1172605 Spring, Clutch | Spring, Clutch | 3 | $8.18 | Backorder — Early October 2026 | 3 |
| 18 | T1179999 Washer, C, Clutch | Washer, C, Clutch | 1 | $11.71 | Available to order | 1 |
| 19 | T1170106 Nut, Clutch, 22mm | Nut, Clutch, 22mm | 1 | $13.51 | Available to order | 1 |
| 20 | T1170112 Housing, Clutch Bearing, Flanged | Housing, Clutch Bearing, Flanged | 5 | $19.21 | Out of Stock | Notify Me |
| 21 | T1170067 Bearing, Pressure Plate | Bearing, Pressure Plate | 1 | $33.23 | Available to order | 1 |
| 22 | T1172528 Lifter Piece, Clutch | Lifter Piece, Clutch | 1 | $47.42 | Available to order | 1 |
| 23 | T1171711 Gasket, Slave Cylinder, Clutch | Gasket, Slave Cylinder, Clutch | 1 | $14.39 | Available to order | 1 |
| 24 | T3205066 Bolt, HHF, Lghtd, M6 x 20, Slv | Bolt, HHF, Lghtd, M6 x 20, Slv | 3 | $4.55 | Available to order | 3 |
| 25 | T1177888 Slave Cylinder | Slave Cylinder | 1 | $138.75 | Available to order | 1 |
| 26 | T2020014 Bleed Screw | Bleed Screw | 1 | $15.27 | Available to order | 1 |
