Triumph Tiger Sport 660cc Handlebars, Top Yoke & Mirrors — OEM Parts Diagram

Engle Motors is your source for OEM Triumph parts and accessories with free shipping on orders of $100+!OEM Triumph parts — free shipping over $100!

Loading schematic...

What Our Customers Say

5 out of 5 based on 710 reviews

View all reviews →

“I like the procedure of verifying the part # with my motorcycle VIN#.”

M. Armfield · LOS ALTOS, CA · Mar 2026

“It would be nice to have better drawings of the parts. These were fuzzy and difficult to make out.”

M. Cohen · Pasadena, CA · Mar 2026

“EASY TO USE WEBSITE, AND GREAT SERVICE!”

J. SHEETS · CINCINNATI, OH · Feb 2026

“You guys are awesome! I Always use you guys for parts! Your diagrams are easy to move through. I will say the cooling system side was a little hard to figure out but praise be that theres a search bar! All n' all, 10/10! Rock on!”

N. Drinkall · BUHL, ID · Feb 2026

“Very efficient process... no hoping on a smooth delivery process. :-)”

P. De Keersmaecker · JACKSONVILLE, FL · Feb 2026

“Thank you, search was easy and glad I found you guys.”

P. Melia · SAINT PETERSBURG, FL · Feb 2026

#	Part Number	Description	Qty	Price	Status
1	T2043367 Handlebar, Tapered, Black	Handlebar, Tapered, Black	1	$189.30	Available to order	1 Ships within 3–7 business days
2	T2046667 Finisher, Bar End, Black	Finisher, Bar End, Black Not TH	2	$32.60	Available to order	2 Ships within 3–7 business days
3	T3330923 Screw, Csk, M6 x 20, Slv, Enc	Screw, Csk, M6 x 20, Slv, Enc	2	$2.37	Available to order	2 Ships within 3–7 business days
4	T2046075 APS Sensor, Assy	APS Sensor, Assy	1	$266.39	Available to order	1 Ships within 3–7 business days
5	T2044707 Grip, RH	Grip, RH	1	$26.65	Available to order	1 Ships within 3–7 business days
6	T3050314 Bolt, M5 x 20	Bolt, M5 x 20	2	$7.02	Available to order	2 Ships within 3–7 business days
7	T2043616 Switchcube, RH	Switchcube, RH	1	$142.01	Available to order	1 Ships within 3–7 business days
8	T2045446 Switchcube, LH	Switchcube, LH	1	$386.44	Available to order	1 Ships within 3–7 business days
9	T2045139 Grip, Handlebar, LH	Grip, Handlebar, LH	1	$26.65	Available to order	1 Ships within 3–7 business days
10	T3330247 Screw, S/Tap, Pan/Hd, M4 x 10, HD	Screw, S/Tap, Pan/Hd, M4 x 10, HD	2	$7.14	Available to order	2 Ships within 3–7 business days
11	T2044709 Handlebar Clamp, Forge	Handlebar Clamp, Forge	1	$100.45	Out of Stock	Notify Me
12	T2043325 Handlebar Riser, LH	Handlebar Riser, LH	1	$80.91	Available to order	1 Ships within 3–7 business days
13	T2043326 Handlebar Riser, RH	Handlebar Riser, RH	1	$80.91	Available to order	1 Ships within 3–7 business days
14	T3050324 Screw, Cap/Hd, M8 x 1.25 x 35, Slv	Screw, Cap/Hd, M8 x 1.25 x 35, Slv	4	$4.74	Available to order	4 Ships within 3–7 business days
15	T2043216 Upper Yoke	Upper Yoke	1	$264.17	Out of Stock	Notify Me
16	T2041120 Nut, Upper Yoke, Black	Nut, Upper Yoke, Black	1	$24.43	Available to order	1 Ships within 3–7 business days
17	T3050323 Screw, Cap/Hd, M8 x 30, Slv	Screw, Cap/Hd, M8 x 30, Slv	2	$4.74	Available to order	2 Ships within 3–7 business days
18	T2044725 Wire Guide	Wire Guide	1	$26.65	Out of Stock	Notify Me
19	T3331042 Screw, Pan/Hd, Tx, M6 x 12, Enc	Screw, Pan/Hd, Tx, M6 x 12, Enc	2	$1.40	Available to order	2 Ships within 3–7 business days
20	T3334690 Screw, HHF, M12 x 50	Screw, HHF, M12 x 50	2	$5.65	Available to order	2 Ships within 3–7 business days
21	T3550314 Washer, M12, Hardened	Washer, M12, Hardened	2	$3.59	Available to order	2 Ships within 3–7 business days
22	T3700259 Rubber Band, 43mm	Rubber Band, 43mm	2	$3.90	Available to order	2 Ships within 3–7 business days
23	T3331857 Screw, Torx, M4 x 0.7 x 18, Blk	Screw, Torx, M4 x 0.7 x 18, Blk	4	$1.78	Available to order	4 Ships within 3–7 business days
24	T2060160 Mirror, LHS	Mirror, LHS	1	$126.04	Available to order	1 Ships within 3–7 business days
25	T2060159 Mirror, RHS	Mirror, RHS	1	$127.93	Available to order	1 Ships within 3–7 business days
26	T3550500 Washer, 4.3 x 9.0 x 0.8	Washer, 4.3 x 9.0 x 0.8	2	$1.72	Available to order	2 Ships within 3–7 business days
27	T2308627 Spacer, Csk	Spacer, Csk TH Only	2	$9.02	Available to order	2 Ships within 3–7 business days
28	T9638840 Handguard Ext Assy, RH	Handguard Ext Assy, RH TH Only	1	$55.02	Out of Stock	Notify Me
29	T9638839 Handguard Ext Assy, LH	Handguard Ext Assy, LH TH Only	1	$55.02	Available to order	1 Ships within 3–7 business days
30	T9709014 Bracket, Handguard, RHS	Bracket, Handguard, RHS TH Only	1	$61.45	Available to order	1 Ships within 3–7 business days
31	T9709013 Bracket, Handguard, LHS	Bracket, Handguard, LHS TH Only	1	$61.45	Backorder — Late July 2026	1
32	T2021566 Bolt, Pivot, M6 x 7.9 Dia	Bolt, Pivot, M6 x 7.9 Dia TH Only	1	$9.49	Available to order	1 Ships within 3–7 business days
33	T2309027 Sleeve, 8.2 x 11.0 x 2.3	Sleeve, 8.2 x 11.0 x 2.3 TH Only	1	$13.33	Available to order	1 Ships within 3–7 business days
34	T9631756 Sleeve, Flgd, 6.2 x 9.7 x 3.75	Sleeve, Flgd, 6.2 x 9.7 x 3.75 TH Only	1	$10.34	Out of Stock	Notify Me
35	T2046521 Nut, Pivot Bolt	Nut, Pivot Bolt TH Only	1	$1.21	Available to order	1 Ships within 3–7 business days
36	T3331040 Screw, TPT, Pan/Hd, M6 x 12, Slv	Screw, TPT, Pan/Hd, M6 x 12, Slv TH Only	2	$2.37	Available to order	2 Ships within 3–7 business days
37	T2309213 Clutch Pivot Bold	Clutch Pivot Bold TH Only	1	$12.38	Available to order	1 Ships within 3–7 business days
