Loading schematic...
Crankshaft, Conrods & Pistons
Parts (17)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T1101212 Crankshaft Assembly | Crankshaft Assembly | 1 | $1701.79 | Available to order | 1 |
| 2 | T3800120 Bearing, 28 x 41 x 21 Wide | Bearing, 28 x 41 x 21 Wide | 1 | $81.75 | Available to order | 1 |
| 3 | T1100808 Key, Crankshaft | Key, Crankshaft | 1 | $13.61 | Available to order | 1 |
| 4 | T1140511 Sprocket, Camdrive, 17T | Sprocket, Camdrive, 17T | 1 | $97.50 | Available to order | 1 |
| 5 | T1100407 Spacer, Hex | Spacer, Hex | 1 | $13.77 | Available to order | 1 |
| 6 | T3050161 Screw, Cap/HD. M8 x 20, Raw | Screw, Cap/HD. M8 x 20, Raw | 1 | $0.97 | Backorder — Early August 2026 | 1 |
| 7 | T1121360 Piston Assembly | Piston Assembly | 3 | $396.11 | Available to order | 3 |
| 8 | T1126050 Piston & Circlip Assembly | Piston & Circlip Assembly | 3 | $193.52 | Available to order | 3 |
| 9 | T1122502 Gudgeon Pin | Gudgeon Pin | 3 | $28.53 | Available to order | 3 |
| 10 | T1126007 Circlip, Piston | Circlip, Piston | 6 | $2.25 | Available to order | 6 |
| 11 | T1121175 Piston Ring Set, Dia 74.0 | Piston Ring Set, Dia 74.0 | 3 | $115.97 | Available to order | 3 |
| 12 | T1110950 Conrod Assembly | Conrod Assembly | 3 | $261.80 | Backorder — Late July 2026 | 3 |
| 13 | T1110451 Bolt, M8 x 37 x 0.75 | Bolt, M8 x 37 x 0.75 | 6 | $20.81 | Backorder — Early August 2026 | 6 |
| 14 | T1110452 Dowel, 3 x 5 | Dowel, 3 x 5 | 6 | $2.85 | Available to order | 6 |
| 15 | T1110401 Bearing Shell | Bearing Shell White | — | $12.04 | Out of Stock | Notify Me |
| 15 | T1110402 Bearing Shell | Bearing Shell Red | — | $12.04 | Available to order | 1 |
| 16 | T1166622 Cylinder Liner, Iron, Dia 74mm | Cylinder Liner, Iron, Dia 74mm | 3 | $250.98 | Available to order | 3 |
