Loading schematic...
Bodywork - Side Panels
Parts (32)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2309410-PG Sidepanel, LH, Painted | Sidepanel, LH, Painted Jet Black; F2 363103 > & F4 363005 > 497345 | 1 | $379.04 | Out of Stock | Notify Me |
| 1 | T2309410-HS Sidepanel, LH, Painted | Sidepanel, LH, Painted Matt Khaki Green; F2 363103 > & F4 363005 > 549451 | 1 | $379.04 | Out of Stock | Notify Me |
| 1 | T2309410-PS Sidepanel, LH, Painted | Sidepanel, LH, Painted Matt Black; 451560 > 549451 | 1 | $199.57 | Out of Stock | Notify Me |
| 1 | T2309410-LS Sidepanel, LH, Painted | Sidepanel, LH, Painted Matt Graphite; 549452 > 656967 | 1 | $379.04 | Available to order | 1 |
| 1 | T2309410-JY Sidepanel, LH, Painted | Sidepanel, LH, Painted Matt Pacific Blue; 606027 > **See Tech News 149** | 1 | $199.57 | Available to order | 1 |
| 1 | T2309410-MM Sidepanel, LH, Painted | Sidepanel, LH, Painted Lunar Silver; 606027 > 656967 **See Tech News 149** | 1 | $379.04 | Out of Stock | Notify Me |
| 1 | T2309536-PG Sidepanel, LH, Painted | Sidepanel, LH, Painted Jet Black panel on Diablo Red/Lunar Silver Bike - 656968 > | 1 | $379.04 | Available to order | 1 |
| 1 | T2309347-PG Sidepanel, LH, Painted | Sidepanel, LH, Painted Jet Black; 675528 > | 1 | $379.04 | Out of Stock | Notify Me |
| 2 | T2309411-PG Sidepanel, RH, Painted | Sidepanel, RH, Painted Jet Black; F2 363103 > & F4 363005 > 450559 | 1 | $192.02 | Out of Stock | Notify Me |
| 2 | T2309411-HS Sidepanel, RH, Painted | Sidepanel, RH, Painted Matt Khaki Green; F2 363103 > & F4 363005 > 549451 | 1 | $192.02 | Out of Stock | Notify Me |
| 2 | T2309411-PS Sidepanel, RH, Painted | Sidepanel, RH, Painted Matt Black; 497346 > 549451 | 1 | $192.02 | Out of Stock | Notify Me |
| 2 | T2309411-LS Sidepanel, RH, Painted | Sidepanel, RH, Painted Matt Graphite; 549452 > 656967 | 1 | $379.04 | Out of Stock | Notify Me |
| 2 | T2309411-JY Sidepanel, RH, Painted | Sidepanel, RH, Painted Matt Pacific Blue; 606027 > **See Tech News 149** | 1 | $379.04 | Out of Stock | Notify Me |
| 2 | T2309411-MM Sidepanel, RH, Painted | Sidepanel, RH, Painted Lunar Silver; 606027 > 656967 **See Tech News 149** | 1 | $379.04 | Out of Stock | Notify Me |
| 2 | T2309537-PG Sidepanel, RH, Painted | Sidepanel, RH, Painted Jet Black panel on Diablo Red/Lunar Silver Bike - 656968 > | 1 | $379.04 | Out of Stock | Notify Me |
| 2 | T2309348-PG Sidepanel, RH, Painted | Sidepanel, RH, Painted Jet Black; 675528 > | 1 | $379.04 | Out of Stock | Notify Me |
| 3 | T2301878 Decal, Sidepanel | Decal, Sidepanel | 2 | $35.35 | Available to order | 2 |
| 3 | T2302479 Decal, Sidepanel, Gold | Decal, Sidepanel, Gold Fit to Blue Panel; 606027 > **See Tech News 149** | 2 | $37.93 | Available to order | 2 |
| 3 | T2302478 Decal, Sidepanel, Black/Red | Decal, Sidepanel, Black/Red Fit to Silver Panel; 606027 > 656967 **See Tech News 149** | 2 | $37.93 | Available to order | 2 |
| 3 | T2302619 Decal, Sidepanel, Silver/Red | Decal, Sidepanel, Silver/Red Fit to Black Panel on Red/Silver Bikes; 656968 > | 2 | $35.35 | Available to order | 2 |
| 4 | T3020003 Grommet | Grommet | 4 | $2.00 | Available to order | 4 |
| 5 | T3335566 Screw, Coin Release, M6 x 20 | Screw, Coin Release, M6 x 20 | 1 | $9.22 | Available to order | 1 |
| 6 | T3010707 Sleeve, Flanged, 6.4 x 10 x 6.5 | Sleeve, Flanged, 6.4 x 10 x 6.5 | 1 | $3.59 | Available to order | 1 |
| 7 | T3020031 Grommet; 11.8 x 2.5 x 10 | Grommet; 11.8 x 2.5 x 10 | 1 | $3.17 | Available to order | 1 |
| 8 | T3020152 Rubber Grommet, Tapered | Rubber Grommet, Tapered | 2 | $2.00 | Available to order | 2 |
| 9 | T2301321 Bracket, Sidepanel/Fusebox | Bracket, Sidepanel/Fusebox | 1 | $13.61 | Available to order | 1 |
| 10 | T2300634 Allen Key, 5mm | Allen Key, 5mm | 1 | $4.92 | Available to order | 1 |
| 11 | T3332568 Screw, But/HD, M5 x 8, Slv | Screw, But/HD, M5 x 8, Slv | 1 | $3.90 | Available to order | 1 |
| 12 | T2301338 Heatshield, Sidepanel | Heatshield, Sidepanel > 340167 - F2 & > 367177 - F4 | 1 | $51.31 | Available to order | 1 |
| 12 | T2301339 Heatshield, Sidepanel, Black | Heatshield, Sidepanel, Black 340168 > - F2 & 367178 > - F4 | 1 | $51.31 | Available to order | 1 |
| 13 | T3300007 Rivet, Barbed, 5.7-7.3mm | Rivet, Barbed, 5.7-7.3mm | 4 | $2.10 | Backorder — Early August 2026 | 4 |
| 14 | T3660171 Pad, Rubber, 30 x 10 x 5, thick | Pad, Rubber, 30 x 10 x 5, thick | 2 | $8.09 | Available to order | 2 |
