Triumph Trophy Front Forks and Yokes 95083» Except VINS 96152» 98479 — OEM Parts Diagram

Engle Motors is your source for OEM Triumph parts and accessories with free shipping on orders of $100+!OEM Triumph parts — free shipping over $100!

Loading schematic...

What Our Customers Say

5 out of 5 based on 710 reviews

View all reviews →

“I like the procedure of verifying the part # with my motorcycle VIN#.”

M. Armfield · LOS ALTOS, CA · Mar 2026

“It would be nice to have better drawings of the parts. These were fuzzy and difficult to make out.”

M. Cohen · Pasadena, CA · Mar 2026

“EASY TO USE WEBSITE, AND GREAT SERVICE!”

J. SHEETS · CINCINNATI, OH · Feb 2026

“You guys are awesome! I Always use you guys for parts! Your diagrams are easy to move through. I will say the cooling system side was a little hard to figure out but praise be that theres a search bar! All n' all, 10/10! Rock on!”

N. Drinkall · BUHL, ID · Feb 2026

“Very efficient process... no hoping on a smooth delivery process. :-)”

P. De Keersmaecker · JACKSONVILLE, FL · Feb 2026

“Thank you, search was easy and glad I found you guys.”

P. Melia · SAINT PETERSBURG, FL · Feb 2026

#	Part Number	Description	Qty	Price	Status
1	T2043015 Stanchion assembly	Stanchion assembly LH	1	$864.14	Obsolete	View Details
2	T2043017 Stanchion assembly	Stanchion assembly RH	1	$864.14	Obsolete	View Details
3	T2040179 Tube outer	Tube outer LH	1	$499.32	Obsolete	View Details
3	T2040180 Tube outer	Tube outer RH	1	$499.32	Obsolete	View Details
4	2040076-T0301 Sliding bush	Sliding bush	2	$14.73	Available to order	2 Ships within 3–7 business days
5	2040077-T0301 Washer	Washer	2	$3.74	Obsolete	View Details
6	2040078-T0301 Oil seal	Oil seal	2	$20.99	Backorder — Early August 2026	2
7	2040079-T0301 Ring snap	Ring snap	2	$6.83	Available to order	2 Ships within 3–7 business days
8	2040080-T0301 Dust seal	Dust seal	2	$20.08	Available to order	2 Ships within 3–7 business days
9	2040160-T0301 Oil lock	Oil lock	2	$9.02	Available to order	2 Ships within 3–7 business days
10	2040171-T0301 Bearing	Bearing	2	$7.14	Backorder — Early August 2026	2
11	2040163-T0301 Cylinder assembly	Cylinder assembly	2	$124.47	Obsolete	View Details
12	2040172-T0301 Bearing	Bearing	2	$9.88	Backorder — Early August 2026	2
13	T2040185 Tube inner	Tube inner	2	$302.81	Available to order	2 Ships within 3–7 business days
14	2042105-T0301 Spring	Spring	2	$91.37	Obsolete	View Details
15	T2045043 Guide spring	Guide spring	2	$11.32	Available to order	2 Ships within 3–7 business days
16	2040168-T0301 Spacer	Spacer	2	$6.99	Obsolete	View Details
17	T2040169 Cap, Fork	Cap, Fork	2	$81.75	Available to order	2 Ships within 3–7 business days
18	2040170-T0301 Capscrew	Capscrew	2	$10.32	Obsolete	View Details
19	2043060-T0301 Washer sealing	Washer sealing	2	$6.73	Available to order	2 Ships within 3–7 business days
20	T2040904 Yoke assembly	Yoke assembly Upper	1	$203.45	Obsolete	View Details
21	T2040940 Yoke assembly	Yoke assembly Lower	1	$363.73	Obsolete	View Details
22	T3051032 Screw, Cap/HD, M8 x 40, Slv	Screw, Cap/HD, M8 x 40, Slv	10	$1.51	Available to order	10 Ships within 3–7 business days
23	T3450060 Cap	Cap	1	$1.40	Available to order	1 Ships within 3–7 business days
24	T2040061 Washer Upper Yoke	Washer Upper Yoke	1	$7.14	Available to order	1 Ships within 3–7 business days
25	T2040060 Nut	Nut	1	$24.83	Out of Stock	Notify Me
26	T2040081 O Ring, Fork Seal	O Ring, Fork Seal	2	$3.59	Available to order	2 Ships within 3–7 business days
27	2040173-T0301 Seal kit	Seal kit	2	$35.44	Available to order	2 Ships within 3–7 business days
28	T2040259 Cover, Headstock Assy	Cover, Headstock Assy Lower	1	$24.33	Out of Stock	Notify Me
29	T2140210 Adjuster Nut, Upper	Adjuster Nut, Upper	1	$3.39	Available to order	1 Ships within 3–7 business days
30	T3450200 Plug, Caphead, Chrome	Plug, Caphead, Chrome	4	$4.19	Available to order	4 Ships within 3–7 business days
31	T2040156 Cover	Cover	1	$22.60	Obsolete	View Details
32	T3450270 Retainer	Retainer	2	$0.75	Available to order	2 Ships within 3–7 business days
33	T3450265 Firtree plug	Firtree plug PART NO LONGER AVAILABLE	2	$1.18	Obsolete	View Details
34	T3900450 Badge, Oval, Plastic	Badge, Oval, Plastic	1	$8.53	Out of Stock	Notify Me
35	T2500028 Bracket	Bracket	1	$3.59	Available to order	1 Ships within 3–7 business days
36	T3550405 Washer, M8 x 17 x 1.6	Washer, M8 x 17 x 1.6	4	$0.89	Available to order	4 Ships within 3–7 business days
