Triumph Trophy 1215 Handlebars & Switches — OEM Parts Diagram

Engle Motors is your source for OEM Triumph parts and accessories with free shipping on orders of $100+!OEM Triumph parts — free shipping over $100!

Loading schematic...

What Our Customers Say

5 out of 5 based on 710 reviews

View all reviews →

“I like the procedure of verifying the part # with my motorcycle VIN#.”

M. Armfield · LOS ALTOS, CA · Mar 2026

“It would be nice to have better drawings of the parts. These were fuzzy and difficult to make out.”

M. Cohen · Pasadena, CA · Mar 2026

“EASY TO USE WEBSITE, AND GREAT SERVICE!”

J. SHEETS · CINCINNATI, OH · Feb 2026

“You guys are awesome! I Always use you guys for parts! Your diagrams are easy to move through. I will say the cooling system side was a little hard to figure out but praise be that theres a search bar! All n' all, 10/10! Rock on!”

N. Drinkall · BUHL, ID · Feb 2026

“Very efficient process... no hoping on a smooth delivery process. :-)”

P. De Keersmaecker · JACKSONVILLE, FL · Feb 2026

“Thank you, search was easy and glad I found you guys.”

P. Melia · SAINT PETERSBURG, FL · Feb 2026

#	Part Number	Description	Qty	Price	Status
1	T2040947 Handlebar, LH	Handlebar, LH	1	$184.39	Out of Stock	Notify Me
2	T2040948 Handlebar, RH	Handlebar, RH	1	$184.39	Available to order	1 Ships within 3–7 business days
3	T2040975 Handlebar weight	Handlebar weight	2	$37.27	Available to order	2 Ships within 3–7 business days
4	T2041030 Bush, Rubber, 27 x 10 x 21	Bush, Rubber, 27 x 10 x 21	2	$17.88	Available to order	2 Ships within 3–7 business days
5	T2040969 Finisher, Handlebar	Finisher, Handlebar	2	$17.69	Available to order	2 Ships within 3–7 business days
6	T3330933 Screw, CSK, M6 x 60, Slv	Screw, CSK, M6 x 60, Slv	2	$0.75	Available to order	2 Ships within 3–7 business days
7	T2040977 Sleeve, Handlebar Weight	Sleeve, Handlebar Weight	2	$8.90	Available to order	2 Ships within 3–7 business days
8	T3050321 Screw, Cap/Hd, M8 x 20, Slv	Screw, Cap/Hd, M8 x 20, Slv	6	$7.42	Available to order	6 Ships within 3–7 business days
9	T2040644 Yoke Assembly, Upper	Yoke Assembly, Upper	1	$369.67	Out of Stock	Notify Me
10	T3050323 Screw, Cap/Hd, M8 x 30, Slv	Screw, Cap/Hd, M8 x 30, Slv	2	$4.74	Available to order	2 Ships within 3–7 business days
11	T2040628 Handlebar, Centre Forging	Handlebar, Centre Forging	1	$51.31	Available to order	1 Ships within 3–7 business days
12	T3050128 Bolt, Skt HD, M10 x 70, Yel	Bolt, Skt HD, M10 x 70, Yel	2	$13.18	Available to order	2 Ships within 3–7 business days
13	T3555030 Washer, 10.5 x 30 x 2.5	Washer, 10.5 x 30 x 2.5	2	$6.65	Backorder — Mid August 2026	2
14	T2049149 Cap, Handlebar Bush	Cap, Handlebar Bush	4	$24.23	Out of Stock	Notify Me
15	T2049191 Bush, Rubber, H/Bar Clamp	Bush, Rubber, H/Bar Clamp	4	$6.07	Available to order	4 Ships within 3–7 business days
16	T2049488 Sleeve, Dia 13 x 43	Sleeve, Dia 13 x 43	2	$4.86	Backorder — Early August 2026	2
17	T2040685 Cover, Ignition Switch	Cover, Ignition Switch	1	$20.53	Available to order	1 Ships within 3–7 business days
18	T3330941 Screw, But/Hd, Skt, M5 x 16, Slv	Screw, But/Hd, Skt, M5 x 16, Slv	2	$6.73	Available to order	2 Ships within 3–7 business days
19	T2041264 Switchcube, APS, RH, Non DRL	Switchcube, APS, RH, Non DRL	1	$244.95	Available to order	1 Ships within 3–7 business days
20	T3331440 Screw, Pan/Hd, Phil, M5 x 40	Screw, Pan/Hd, Phil, M5 x 40	3	$2.00	Available to order	3 Ships within 3–7 business days
21	T2047165 Grip, Handlebar, RH	Grip, Handlebar, RH	1	$18.33	Available to order	1 Ships within 3–7 business days
22	T3550249 Washer, 11 x 5.1 x 0.8	Washer, 11 x 5.1 x 0.8	2	$2.25	Available to order	2 Ships within 3–7 business days
23	T2042153 Switch Pod, Screen Adj, Front	Switch Pod, Screen Adj, Front	1	$146.96	Obsolete	View Details
24	T2042148 Switch Pod, Screen Adj, Rear	Switch Pod, Screen Adj, Rear	1	$58.20	Obsolete	View Details
25	T2042035 Switch Cube Assy, LH	Switch Cube Assy, LH	1	$311.19	Available to order	1 Ships within 3–7 business days
26	T3331795 Screw, M5 x 35	Screw, M5 x 35	2	$1.62	Available to order	2 Ships within 3–7 business days
27	T2047164 Grip, Handlebar, LH	Grip, Handlebar, LH	1	$18.33	Out of Stock	Notify Me
28	T3330247 Screw, S/Tap, Pan/Hd, M4 x 10, HD	Screw, S/Tap, Pan/Hd, M4 x 10, HD	2	$7.14	Available to order	2 Ships within 3–7 business days
29	T3331750 Screw, Tx, M4 x 17.5, Slv	Screw, Tx, M4 x 17.5, Slv	2	$4.30	Available to order	2 Ships within 3–7 business days
30	T3330627 Screw, Pan/HD, TPT, Tx, M5 x 12	Screw, Pan/HD, TPT, Tx, M5 x 12	2	$0.97	Available to order	2 Ships within 3–7 business days
31	T3050343 Screw, Cap/Hd, M5 x 30, Slv	Screw, Cap/Hd, M5 x 30, Slv	1	$4.45	Available to order	1 Ships within 3–7 business days
32	T3700212 Band, Rubber	Band, Rubber	3	$3.29	Available to order	3 Ships within 3–7 business days
33	T3700015 Cable Tie, 185.7 Long	Cable Tie, 185.7 Long	1	$0.89	Available to order	1 Ships within 3–7 business days
