Loading schematic...
Ignition System
Parts (27)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T1299380 ECM Base | ECM Base > 437492 **See Tech News 118** | 1 | $1091.45 | Available to order | 1 |
| 1 | T1299315 ECM Base | ECM Base 437493 > **See Tech News 118** | 1 | $1091.45 | Available to order | 1 |
| 2 | T2500711 Bracket, ECM, Moulded | Bracket, ECM, Moulded > 463261 | 1 | $19.88 | Obsolete | View Details |
| 2 | T2500717 Retainer, ECM, Moulded | Retainer, ECM, Moulded 463262 > | 1 | $21.86 | Available to order | 1 |
| 3 | T1292015 Air Pressure Sensor | Air Pressure Sensor | 3 | $142.58 | Available to order | 3 |
| 4 | T1291633 Hose, Map Sensor, RH | Hose, Map Sensor, RH | 1 | $25.65 | Available to order | 1 |
| 5 | T1291632 Hose, Map Sensor, LH | Hose, Map Sensor, LH | 1 | $25.38 | Available to order | 1 |
| 6 | T1290270 Bracket, Map Sensor & Relay | Bracket, Map Sensor & Relay | 1 | $23.00 | Backorder — Late July 2026 | 1 |
| 7 | T3205063 Bolt, HHF, Lghtd, M6 x 16, Slv | Bolt, HHF, Lghtd, M6 x 16, Slv | 5 | $3.50 | Available to order | 5 |
| 8 | T1290024 Spark Plug, DPR8EA-9 | Spark Plug, DPR8EA-9 | 2 | $7.34 | Available to order | 2 |
| 9 | T1290101 Coil, Twin Output | Coil, Twin Output | 1 | $201.51 | Available to order | 1 |
| 10 | T1290260 Bracket, Pressed Coil | Bracket, Pressed Coil | 1 | $15.88 | Available to order | 1 |
| 11 | T3331041 Screw, Pan/Hd, Tx, M6 x 25, Enc | Screw, Pan/Hd, Tx, M6 x 25, Enc | 2 | $1.06 | Available to order | 2 |
| 12 | T3330627 Screw, Pan/HD, TPT, Tx, M5 x 12 | Screw, Pan/HD, TPT, Tx, M5 x 12 | 2 | $0.97 | Available to order | 2 |
| 13 | T1291653 HT Lead, 2 Cyl Short Conn | HT Lead, 2 Cyl Short Conn | 1 | $105.96 | Obsolete | View Details |
| 14 | T1294225 Sensor, Water Temperature | Sensor, Water Temperature | 1 | $53.40 | Available to order | 1 |
| 15 | T3550571 Washer, Cu, OD 16 x ID 12.5 | Washer, Cu, OD 16 x ID 12.5 | 1 | $5.07 | Available to order | 1 |
| 16 | T2204191 Oxygen Sensor Spares Kit | Oxygen Sensor Spares Kit | 2 | $219.06 | Available to order | 2 |
| 17 | T1290088 Sensor, Air Temperature | Sensor, Air Temperature | 1 | $64.75 | Available to order | 1 |
| 18 | T3050341 Screw, Cap/Hd, M5 x 10, Slv | Screw, Cap/Hd, M5 x 10, Slv | 1 | $3.80 | Available to order | 1 |
| 19 | T1291652 Ht Lead, 2 Cyl, Long Conn | Ht Lead, 2 Cyl, Long Conn *Part No Longer Available* | 1 | $118.15 | Obsolete | View Details |
| 20 | T1290131 Crankshaft Position Sensor/Ignition Pick-Up | Crankshaft Position Sensor/Ignition Pick-Up > 437492 **See Tech News 118** | 1 | $106.47 | Available to order | 1 |
| 20 | T1296505 Sensor, Ignition, V-Grommet | Sensor, Ignition, V-Grommet 437493 > **See Tech News 118** | 1 | $110.28 | Available to order | 1 |
| 21 | T3331042 Screw, Pan/Hd, Tx, M6 x 12, Enc | Screw, Pan/Hd, Tx, M6 x 12, Enc > 437492 **See Tech News 118** | 2 | $1.40 | Available to order | 2 |
| 21 | T3051055 Screw, Cap/Hd, M5 x 10, Slv, Enc | Screw, Cap/Hd, M5 x 10, Slv, Enc 437493 > **See Tech News 118** | 2 | $3.04 | Available to order | 2 |
| 22 | T1293000 Sensor, Road Speed | Sensor, Road Speed 437493 > **See Tech News 118** | 1 | $237.62 | Available to order | 1 |
| 23 | T3330334 Screw, Tx, Pan/Hd, M6 x 16, Slv | Screw, Tx, Pan/Hd, M6 x 16, Slv 437493 > **See Tech News 118** | 1 | $2.63 | Available to order | 1 |
