Loading schematic...
Footboard Kit
Schematic
Parts (26)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | A9770117 Footboard Kit | Footboard Kit Also requires either A9600656, A9600658 or A9600660 - and requires 9770195 (up to Vin 854155) and 9770179 (from Vin 854156) | 1 | $775.00 | Out of Stock | Notify Me |
| 2 | T9770160 Bracket, Footboard, RH | Bracket, Footboard, RH | 1 | $73.42 | Out of Stock | Notify Me |
| 3 | T9770161 Bracket, Footboard, LH | Bracket, Footboard, LH | 1 | $73.42 | Available to order | 1 |
| 4 | T9770193 Brake Pedal | Brake Pedal | 1 | $144.61 | Out of Stock | Notify Me |
| 5 | T9770194 Gear Lever, Rocker | Gear Lever, Rocker | 1 | $161.30 | Backorder — Mid August 2026 | 1 |
| 6 | T2026182 Rubber, Gear Pedal | Rubber, Gear Pedal | 2 | $10.81 | Available to order | 2 |
| 7 | T2081746 Gearchange Pin | Gearchange Pin | 2 | $10.34 | Available to order | 2 |
| 8 | T2085037 Ball Joint, M6, RH | Ball Joint, M6, RH Replaced with T2086070 | 1 | $21.08 | Obsolete | View Details |
| 8 | T2086070 Ball Joint, M6, RH | Ball Joint, M6, RH | 1 | $25.46 | Out of Stock | Notify Me |
| 9 | T3051097 Screw, Cap/Hd, M8 x 25, Silver | Screw, Cap/Hd, M8 x 25, Silver | 4 | $4.12 | Available to order | 4 |
| 10 | T2086100 Clamp Assembly, Gearchange | Clamp Assembly, Gearchange | 1 | $72.92 | Obsolete | View Details |
| 11 | T9770191 Rubber, Footboard, LHF | Rubber, Footboard, LHF | 1 | $48.95 | Out of Stock | Notify Me |
| 12 | T9770190 Rubber, Footboard, RHF | Rubber, Footboard, RHF | 1 | $48.95 | Available to order | 1 |
| 13 | T2081298 Casting, Footboard, LHF, Chrome | Casting, Footboard, LHF, Chrome | 1 | $165.39 | Available to order | 1 |
| 14 | T2081297 Casting, Footboard, RHF, Chrome | Casting, Footboard, RHF, Chrome | 1 | $165.39 | Available to order | 1 |
| 15 | T2081284 Downstop, Rubber, Footboard | Downstop, Rubber, Footboard | 2 | $11.79 | Available to order | 2 |
| 16 | T2083232 Spring, Footboard Return | Spring, Footboard Return | 2 | $5.56 | Available to order | 2 |
| 17 | T2083017 Pivot Pin | Pivot Pin | 2 | $17.77 | Available to order | 2 |
| 18 | T3500207 Circlip, Ext 8 X 0.89 | Circlip, Ext 8 X 0.89 | 2 | $2.85 | Available to order | 2 |
| 19 | T3750022 Bush, 8 x 10 x 8, Zero Tol | Bush, 8 x 10 x 8, Zero Tol | 12 | $12.55 | Available to order | 12 |
| 20 | T3331520 Bolt, Shld, M8 x 1.25, Slv, Enc | Bolt, Shld, M8 x 1.25, Slv, Enc | 1 | $10.63 | Available to order | 1 |
| 21 | T3332568 Screw, But/HD, M5 x 8, Slv | Screw, But/HD, M5 x 8, Slv | 4 | $3.90 | Available to order | 4 |
| 22 | T2080753 Bank Angle Indicator | Bank Angle Indicator | 2 | $21.86 | Available to order | 2 |
| 23 | T3330895 Bolt, Shld, M10 x 1.25 | Bolt, Shld, M10 x 1.25 | 1 | $14.23 | Available to order | 1 |
| 24 | T3330275 Screw, But/Hd, Tx, M8 x 20, Enc | Screw, But/Hd, Tx, M8 x 20, Enc | 1 | $3.59 | Available to order | 1 |
| 27 | T2082937 Washer, 6.4 x 11 x 1.6 | Washer, 6.4 x 11 x 1.6 | 1 | $1.28 | Available to order | 1 |
