Loading schematic...
Rear Wheel
Parts (32)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2011981 Rear Wheel Assembly, 16 x 3.5 | Rear Wheel Assembly, 16 x 3.5 | 1 | $997.81 | Out of Stock | Notify Me |
| 2 | T2011982 Rim, Rear, 16 x 3.5, Aluminium | Rim, Rear, 16 x 3.5, Aluminium | 1 | — | Unavailable | View Details |
| 3 | T2013579 Spoke, Rear, 141mm | Spoke, Rear, 141mm | 32 | $7.02 | Available to order | 32 |
| 4 | T2005003 Nipple, Steel, Spoke | Nipple, Steel, Spoke | 32 | $6.39 | Available to order | 32 |
| 5 | T3800096 Bearing Ball, 20 47 14 | Bearing Ball, 20 47 14 | 2 | $35.08 | Available to order | 2 |
| 6 | T3500012 Circlip, Int Dia 47 | Circlip, Int Dia 47 | 1 | $3.90 | Available to order | 1 |
| 7 | T2012337 Spacer, Rear Wheel | Spacer, Rear Wheel | 1 | $32.03 | Available to order | 1 |
| 8 | T3600046 Oil Seal, 28 47 7 | Oil Seal, 28 47 7 | 1 | $18.91 | Available to order | 1 |
| 9 | T2010379 Spacer, Top Hat, 18 Long | Spacer, Top Hat, 18 Long | 1 | $12.38 | Available to order | 1 |
| 10 | T2010647 Spacer Tube, 35 x 20 x 12.5 | Spacer Tube, 35 x 20 x 12.5 | 1 | $8.09 | Out of Stock | Notify Me |
| 11 | T2010492 Spacer, Stepped | Spacer, Stepped | 1 | $19.37 | Available to order | 1 |
| 12 | T2010520 Rear Wheel Spindle | Rear Wheel Spindle | 1 | $104.56 | Backorder — Early August 2026 | 1 |
| 13 | T2011062 Adjuster, Rear Wheel | Adjuster, Rear Wheel | 1 | $15.27 | Available to order | 1 |
| 14 | T2011052 Adjuster, Rear Wheel | Adjuster, Rear Wheel | 1 | $15.27 | Available to order | 1 |
| 15 | T3555035 Washer, 19 x 34 x 3 | Washer, 19 x 34 x 3 | 1 | $1.27 | Available to order | 1 |
| 16 | T3350118 Locknut, Plain, M18 | Locknut, Plain, M18 | 1 | $11.56 | Backorder — Late July 2026 | 1 |
| 17 | T2010606 Sprocket Carrier Assy, Black | Sprocket Carrier Assy, Black | 1 | $378.49 | Available to order | 1 |
| 18 | T2012144 Stud, Sprocket Carrier | Stud, Sprocket Carrier | 6 | $7.62 | Available to order | 6 |
| 19 | T2010630 Bearing, Ring | Bearing, Ring | 1 | $54.20 | Available to order | 1 |
| 20 | T3800029 Bearing Ball, 25 52 15 | Bearing Ball, 25 52 15 | 1 | $16.31 | Available to order | 1 |
| 21 | T3500203 Circlip, Int, 52 x 2 | Circlip, Int, 52 x 2 | 1 | $16.04 | Available to order | 1 |
| 22 | T3600073 Oil Seal, 35 52 6 | Oil Seal, 35 52 6 | 1 | $21.86 | Available to order | 1 |
| 23 | T2010314 Rubber, Cush Drive | Rubber, Cush Drive | 1 | $136.88 | Available to order | 1 |
| 24 | T2012537 Sprocket, Rear, 37T, 525 | Sprocket, Rear, 37T, 525 | 1 | $65.49 | Out of Stock | Notify Me |
| 25 | T2011321 Chain, Split, 525V11, 108L | Chain, Split, 525V11, 108L | 1 | $229.07 | Available to order | 1 |
| 25 | T2011320 Soft Link, Chain, Final Drive, 525 EK | Soft Link, Chain, Final Drive, 525 EK | 1 | $30.48 | Available to order | 1 |
| 25 | T2011453 Con Link, 525 Chain, Spares | Con Link, 525 Chain, Spares | 1 | $16.43 | Available to order | 1 |
| 26 | T3350250 Locknut, Flanged, M10 | Locknut, Flanged, M10 | 6 | $4.16 | Available to order | 6 |
| 27 | T2019920 Rim Band, 38mm x 15"/16" | Rim Band, 38mm x 15"/16" | 1 | $13.67 | Available to order | 1 |
| 28 | T2011743 Inner Tube, 16" | Inner Tube, 16" | 1 | $68.25 | Available to order | 1 |
| 29 | T2006699 Wheel Weight, 5 Gram | Wheel Weight, 5 Gram | — | $7.90 | Available to order | 1 |
| 30 | T2011337 Chain & Sprocket Kit, 108/37/17 | Chain & Sprocket Kit, 108/37/17 | 1 | $284.51 | Backorder — Early September 2026 | 1 |
