Loading schematic...
Luggage
Parts (34)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | 2350245-T0301 Top rack | Top rack | 1 | $148.71 | Obsolete | View Details |
| 2 | 3010250-T0301 Flanged sleeve | Flanged sleeve | 2 | $5.63 | Obsolete | View Details |
| 3 | T3700015 Cable Tie, 185.7 Long | Cable Tie, 185.7 Long | 3 | $0.89 | Available to order | 3 |
| 5 | 2350070-T0301 Side frame rh | Side frame rh | 1 | $114.00 | Obsolete | View Details |
| 6 | 2350080-T0301 Side frame lh | Side frame lh | 1 | $114.00 | Obsolete | View Details |
| 7 | 2350090-T0301 Mounting kit | Mounting kit | 1 | $9.65 | Obsolete | View Details |
| 8 | 2350100-T0301 Stay | Stay | 1 | $21.45 | Obsolete | View Details |
| 9 | 2350110-T0301 Angle bracket | Angle bracket | 2 | $17.15 | Obsolete | View Details |
| 10 | 2700231-T0301 Indicator assembly | Indicator assembly RH | 1 | $47.85 | Obsolete | View Details |
| 11 | 2700241-T0301 Indicator assembly | Indicator assembly LH | 1 | $47.85 | Obsolete | View Details |
| 12 | T3051062 Screw, M6 x 12, Enc, Raw | Screw, M6 x 12, Enc, Raw M6 x 12mm | 2 | $1.47 | Available to order | 2 |
| 13 | 3200130-T0301 Bolt | Bolt M10 x 35mm - PART NO LONGER AVAILABLE | 2 | $0.94 | Obsolete | View Details |
| 14 | T3331044 Screw, Pan/Hd, Tx, M6 x 16, Slv | Screw, Pan/Hd, Tx, M6 x 16, Slv M6 x 16mm | 4 | $0.97 | Available to order | 4 |
| 15 | 3330065-T0301 Screw | Screw M6 x 30mm | 2 | $0.45 | Obsolete | View Details |
| 16 | 3330070-T0301 Screw | Screw M6 x 55mm | 2 | $2.96 | Obsolete | View Details |
| 17 | T3350003 Locknut, Flanged, M6 x 1 | Locknut, Flanged, M6 x 1 | 2 | $0.67 | Available to order | 2 |
| 18 | 3350030-T0301 Nut m10 | Nut m10 | 2 | $1.11 | Available to order | 2 |
| 19 | 3450150-T0301 Grommet | Grommet 22mm dia | 2 | $1.22 | Obsolete | View Details |
| 20 | 3450160-T0301 Grommet | Grommet 5mm dia | 8 | $1.18 | Obsolete | View Details |
| 21 | T3551283 Washer, M10, 10.5x18x1.6, Slv | Washer, M10, 10.5x18x1.6, Slv | 4 | $2.00 | Available to order | 4 |
| 22 | 3700017-T0301 Cable tie | Cable tie | 8 | $0.90 | Obsolete | View Details |
| 23 | 3850150-T0301 Instructions | Instructions Not illustrated | 1 | $3.90 | Obsolete | View Details |
| 24 | 3900190-T0301 Warning label | Warning label UK, NZ, AU, ZA, GR, CY, HK, MY | 1 | — | Unavailable | View Details |
| 24 | 3910180-T0301 Label | Label PART NO LONGER AVAILABLE - CH, DE | 1 | — | Unavailable | View Details |
| 24 | 3901190-T0301 Warning label | Warning label NL | 1 | $6.84 | Obsolete | View Details |
| 24 | 3902190-T0301 Warning label | Warning label FR | 1 | $3.43 | Obsolete | View Details |
| 24 | 3903190-T0301 Warning label | Warning label IT | 1 | $4.76 | Obsolete | View Details |
| 24 | 3904190-T0301 Warning label | Warning label PART NO LONGER AVAILABLE - AR, ES | 1 | $5.33 | Obsolete | View Details |
| 24 | 3906190-T0301 Warning label | Warning label PART NO LONGER AVAILABLE - JP | 1 | $5.33 | Obsolete | View Details |
| 24 | 3907190-T0301 Warning label | Warning label PART NO LONGER AVAILABLE - BR, PT | 1 | $5.33 | Obsolete | View Details |
| 25 | 2350170-T0301 Motif | Motif | 2 | $11.47 | Obsolete | View Details |
| 27 | 2350120-T0301 Trim kit | Trim kit Midnight Blue | 1 | $34.92 | Obsolete | View Details |
| 27 | 2350126-T0301 Trim kit | Trim kit Lancaster Red Radiant Red | 1 | $34.92 | Obsolete | View Details |
| 28 | 2350005-T0301 Frame kit | Frame kit | 1 | $275.00 | Obsolete | View Details |
