Triumph Daytona Bodywork - Side Fairings — OEM Parts Diagram

Engle Motors is your source for OEM Triumph parts and accessories with free shipping on orders of $100+!OEM Triumph parts — free shipping over $100!

Loading schematic...

What Our Customers Say

5 out of 5 based on 710 reviews

View all reviews →

“I like the procedure of verifying the part # with my motorcycle VIN#.”

M. Armfield · LOS ALTOS, CA · Mar 2026

“It would be nice to have better drawings of the parts. These were fuzzy and difficult to make out.”

M. Cohen · Pasadena, CA · Mar 2026

“EASY TO USE WEBSITE, AND GREAT SERVICE!”

J. SHEETS · CINCINNATI, OH · Feb 2026

“You guys are awesome! I Always use you guys for parts! Your diagrams are easy to move through. I will say the cooling system side was a little hard to figure out but praise be that theres a search bar! All n' all, 10/10! Rock on!”

N. Drinkall · BUHL, ID · Feb 2026

“Very efficient process... no hoping on a smooth delivery process. :-)”

P. De Keersmaecker · JACKSONVILLE, FL · Feb 2026

“Thank you, search was easy and glad I found you guys.”

P. Melia · SAINT PETERSBURG, FL · Feb 2026

#	Part Number	Description	Qty	Price	Status
1	T2304753-FD Side fairing LH	Side fairing LH » 186150 Acidic Yellow - Includes Decal	1	$567.61	Obsolete	View Details
1	T2304753-JD Side fairing LH	Side fairing LH » 161317 Caspian Blue - Includes Decal	1	$507.66	Obsolete	View Details
1	T2304753-MH Side fairing LH	Side fairing LH » 161317 Aluminium Silver - Includes Decal	1	$567.61	Obsolete	View Details
1	T2304753-HH Side fairing LH	Side fairing LH » 161317 Aston Green - Includes Decal	1	$507.66	Obsolete	View Details
1	T2304753-CM Side fairing LH	Side fairing LH » 186150 Tornado Red - Includes Decal	1	$610.88	Obsolete	View Details
1	T2304753-PG Side fairing LH	Side fairing LH » 186150 Jet Black - Includes Decal	1	$567.61	Obsolete	View Details
1	T2304812-FA Side fairing LH	Side fairing LH Racing Yellow 186151 » 227651 - Includes Decal	1	$514.43	Obsolete	View Details
1	T2304812-CM Side fairing LH	Side fairing LH 186151 » Tornado Red - Includes Decal	1	$489.93	Obsolete	View Details
1	T2304812-PG Side fairing LH	Side fairing LH 186151 » Jet Black - Includes Decal	1	$489.93	Obsolete	View Details
1	T2304753-FE Fairing, Side, LH	Fairing, Side, LH Scorched Yellow 227652 > 238222 - Includes Decal	1	$561.58	Obsolete	View Details
1	T2304753-FG Fairing, Side, LH	Fairing, Side, LH Scorched Yellow 238223 > - Includes Decal	1	$542.86	Obsolete	View Details
2	T2304940 Bracket lh	Bracket lh Upper	1	$2.63	Available to order	1 Ships within 3–7 business days
3	T2304901 Bracket, Fairing, Front, LH	Bracket, Fairing, Front, LH	1	$17.99	Available to order	1 Ships within 3–7 business days
4	T2304920 Bracket, Fairing, Lower, LH	Bracket, Fairing, Lower, LH Lower	1	$6.39	Available to order	1 Ships within 3–7 business days
5	T3330848 Bolt, But/Hd, M6 x 21, Shld, Slv	Bolt, But/Hd, M6 x 21, Shld, Slv	6	$5.88	Available to order	6 Ships within 3–7 business days
6	T3350111 Nut, Captive, M6	Nut, Captive, M6	4	$4.92	Backorder — Early August 2026	4
7	T3205063 Bolt, HHF, Lghtd, M6 x 16, Slv	Bolt, HHF, Lghtd, M6 x 16, Slv	1	$3.50	Available to order	1 Ships within 3–7 business days
8	T2304770 Duct intake	Duct intake » 186150 LH	1	$78.87	Available to order	1 Ships within 3–7 business days
8	T2304772-FA Duct intake	Duct intake Racing Yellow 186151 » 227651	1	$59.96	Obsolete	View Details
8	T2304772-CM Duct intake	Duct intake 186151 » Tornado Red	1	$58.84	Obsolete	View Details
8	T2304772-PG Duct intake	Duct intake 186151 » Jet Black	1	$77.01	Available to order	1 Ships within 3–7 business days
8	T2304772-FE Moulding, Intake Duct, LH	Moulding, Intake Duct, LH Scorched Yellow 227652 > 238222	1	$65.35	Obsolete	View Details
8	T2304772-FG Moulding, Intake Duct, LH	Moulding, Intake Duct, LH Scorched Yellow 238223 >	1	$58.99	Obsolete	View Details
9	T2304751 Foam pad	Foam pad Upper LH	1	$9.41	Available to order	1 Ships within 3–7 business days
10	T2304752 Foam pad	Foam pad Lower LH	1	$26.69	Available to order	1 Ships within 3–7 business days
11	T3202304 Bolt, RHHF, M6 x 20, Slv	Bolt, RHHF, M6 x 20, Slv	2	$5.30	Available to order	2 Ships within 3–7 business days
12	T3010707 Sleeve, Flanged, 6.4 x 10 x 6.5	Sleeve, Flanged, 6.4 x 10 x 6.5	2	$3.59	Available to order	2 Ships within 3–7 business days
13	T3020031 Grommet; 11.8 x 2.5 x 10	Grommet; 11.8 x 2.5 x 10	2	$3.17	Available to order	2 Ships within 3–7 business days
14	T3351052 Nut, Captive, 4-5.5mm	Nut, Captive, 4-5.5mm M5	4	$4.36	Available to order	4 Ships within 3–7 business days
15	T2304743-FD Side fairing RH	Side fairing RH » 186150 Acidic Yellow - Includes Decal	1	$533.04	Obsolete	View Details
15	T2304743-JD Side fairing RH	Side fairing RH » 161317 Caspian Blue - Includes Decal	1	$507.66	Obsolete	View Details
15	T2304743-MH Side fairing RH	Side fairing RH » 161317 Aluminium Silver - Includes Decal	1	$737.10	Obsolete	View Details
15	T2304743-HH Side fairing RH	Side fairing RH » 161317 Aston Green - Includes Decal	1	$507.66	Obsolete	View Details
15	T2304743-CM Side fairing RH	Side fairing RH » 186150 Tornado Red - Includes Decal * PART NO LONGER AVAILABLE *	1	$533.04	Obsolete	View Details
15	T2304743-PG Side fairing RH	Side fairing RH » 186150 Jet Black - Includes Decal	1	$533.04	Obsolete	View Details
15	T2304811-FA Side Fairing, RH	Side Fairing, RH Racing Yellow 186151 » 227651 - Includes Decal	1	$489.93	Obsolete	View Details
15	T2304811-CM Side Fairing, RH	Side Fairing, RH Tornado Red 186151 > - Includes Decal	1	$511.46	Obsolete	View Details
15	T2304811-PG Side Fairing, RH	Side Fairing, RH Jet Black 186151 > - Includes Decal * PART NO LONGER AVAILABLE *	1	$793.29	Obsolete	View Details
15	T2304743-FE Fairing, Side, RH	Fairing, Side, RH Scorched Yellow 227652 > 238222 - Includes Decal	1	$533.04	Obsolete	View Details
15	T2304743-FG Fairing, Side, RH	Fairing, Side, RH Scorched Yellow 238223 > - Includes Decal	1	$507.66	Obsolete	View Details
16	T2304930 Bracket rh	Bracket rh	1	$2.63	Available to order	1 Ships within 3–7 business days
17	T2304891 Bracket, Fairing, Front, RH	Bracket, Fairing, Front, RH	1	$17.69	Obsolete	View Details
18	T2304910 Bracket, Fairing, Lower, RH	Bracket, Fairing, Lower, RH	1	$5.14	Obsolete	View Details
19	T3331063 Bolt, But/Hd, M5 x 17, Slv	Bolt, But/Hd, M5 x 17, Slv	2	$2.17	Available to order	2 Ships within 3–7 business days
20	T2304760 Duct intake	Duct intake » 186150 RH	1	$39.18	Available to order	1 Ships within 3–7 business days
20	T2304762-FA Duct intake	Duct intake Racing Yellow 186151 » 227651	1	$56.15	Obsolete	View Details
20	T2304762-CM Duct intake	Duct intake Tornado Red RH 186151 >	1	$61.55	Obsolete	View Details
20	T2304762-PG Duct intake	Duct intake 186151 » Jet Black RH	1	$77.01	Available to order	1 Ships within 3–7 business days
20	T2304762-FE Moulding, Intake Duct, RH	Moulding, Intake Duct, RH Scorched Yellow 227652 > 238222	1	$65.35	Obsolete	View Details
20	T2304762-FG Moulding, Intake Duct, RH	Moulding, Intake Duct, RH SCORCHED YELLOW 238222 >	1	$63.18	Obsolete	View Details
21	T2304950 Panel infill	Panel infill	1	$91.68	Obsolete	View Details
22	T3330941 Screw, But/Hd, Skt, M5 x 16, Slv	Screw, But/Hd, Skt, M5 x 16, Slv	2	$6.73	Available to order	2 Ships within 3–7 business days
23	T2304741 Foam pad	Foam pad Upper RH	1	$9.41	Available to order	1 Ships within 3–7 business days
24	T2304742 Foam pad	Foam pad Lower RH	1	$20.07	Obsolete	View Details
