Loading schematic...
Ignition Switch & Lockset
Parts (24)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T2505607 Lockset | Lockset Includes 2 keys | 1 | $589.72 | Available to order | 1 |
| 2 | T2505609 Ignition Lock, Combined | Ignition Lock, Combined Includes 2 keys | 1 | $272.86 | Available to order | 1 |
| 3 | T2504557 Key, Cut, Immobiliser | Key, Cut, Immobiliser Supplied as pair | 1 | $79.02 | Out of Stock | Notify Me |
| 3 | T2504558 Key, Blank, Immobiliser | Key, Blank, Immobiliser Supplied as single | 1 | $72.26 | Available to order | 1 |
| 4 | T2500612 Fuel Filler Cap, Non Vented | Fuel Filler Cap, Non Vented Includes 2 keys | 1 | $212.94 | Available to order | 1 |
| 5 | T2500622 Seal, Filler Cap, Breather | Seal, Filler Cap, Breather | 1 | $6.14 | Available to order | 1 |
| 6 | T2505611 Lock Assembly, Seat | Lock Assembly, Seat Includes 2 keys | 1 | $119.76 | Available to order | 1 |
| 7 | T2505610 Seat Lock, Panel Mount | Seat Lock, Panel Mount | 1 | $40.38 | Available to order | 1 |
| 8 | T2505616 Clip, Seat Lock | Clip, Seat Lock | 1 | $9.97 | Available to order | 1 |
| 9 | T2505620 Latch Cable Assembly | Latch Cable Assembly | 1 | $33.93 | Available to order | 1 |
| 10 | T2500506 Seat Latch Housing | Seat Latch Housing | 1 | $33.01 | Available to order | 1 |
| 11 | T2505540 Cable Seat Lock | Cable Seat Lock | 1 | $28.60 | Available to order | 1 |
| 12 | T3205067 Bolt, HHF, Lghtd, M6 x 25, Slv | Bolt, HHF, Lghtd, M6 x 25, Slv | 2 | $2.46 | Available to order | 2 |
| 13 | T3330327 Bolt, Shear, M6 x 22, Enc | Bolt, Shear, M6 x 22, Enc | 2 | $5.24 | Available to order | 2 |
| 14 | T3550436 Washer, M6, Elongated | Washer, M6, Elongated | 2 | $4.45 | Available to order | 2 |
| 15 | T3050341 Screw, Cap/Hd, M5 x 10, Slv | Screw, Cap/Hd, M5 x 10, Slv | 3 | $3.80 | Available to order | 3 |
| 16 | T3050343 Screw, Cap/Hd, M5 x 30, Slv | Screw, Cap/Hd, M5 x 30, Slv | 3 | $4.45 | Available to order | 3 |
| 17 | T3050342 Screw, Cap/Hd, M5 x 16, Slv | Screw, Cap/Hd, M5 x 16, Slv | 1 | $2.85 | Available to order | 1 |
| 18 | T2505617 Cable Bracket, Seat Lock | Cable Bracket, Seat Lock | 1 | $29.37 | Available to order | 1 |
| 19 | T2504061 Immobiliser ECU, with RF 434 | Immobiliser ECU, with RF 434 All Mkts Expt JP | 1 | $1452.32 | Backorder — Early August 2026 | 1 |
| 19 | T2504071 Immobiliser ECU, with RF 315 | Immobiliser ECU, with RF 315 JP Only | 1 | $1452.32 | Available to order | 1 |
| 20 | T3332464 Screw, S/Tap, Tx, 5 x 25 | Screw, S/Tap, Tx, 5 x 25 | 2 | $2.17 | Available to order | 2 |
| 21 | T3350305 Locknut, Flgd, M6 x 1.0, Slv | Locknut, Flgd, M6 x 1.0, Slv | 2 | $1.91 | Available to order | 2 |
| 22 | T3555026 Washer, 6.4 x 18 x 1.6 | Washer, 6.4 x 18 x 1.6 | 2 | $1.21 | Available to order | 2 |
