Gearchange Mechanism
Parts (27)
| # | Part Number | Description | Qty | Price | Status | |
|---|---|---|---|---|---|---|
| 1 | T1190919 Gearchange Mechanism Assembly | Gearchange Mechanism Assembly | 1 | $162.94 | Available to order | 1 |
| 2 | T1190107 Detent Arm Assembly | Detent Arm Assembly | 1 | $24.43 | Available to order | 1 |
| 3 | T3502535 Circlip, Din 471, Dia. 14.0 | Circlip, Din 471, Dia. 14.0 | 2 | $1.91 | Available to order | 2 |
| 4 | T3550236 Washer, 14 x 20 x 1.6 | Washer, 14 x 20 x 1.6 | 2 | $2.95 | Available to order | 2 |
| 5 | T1193333 Spring, Gearchange, Return | Spring, Gearchange, Return | 1 | $4.74 | Available to order | 1 |
| 6 | T1190326 Kit, Detent Wheel & Plate | Kit, Detent Wheel & Plate | 1 | $90.30 | Available to order | 1 |
| 7 | T1190123 Spring, Pivot Plate | Spring, Pivot Plate | 1 | $13.01 | Out of Stock | Notify Me |
| 8 | T3555003 Washer, 12 x 18 x 1.2 | Washer, 12 x 18 x 1.2 | 1 | $1.40 | Available to order | 1 |
| 9 | T3500068 Circlip, Din 471, Dia 12 | Circlip, Din 471, Dia 12 | 1 | $1.91 | Available to order | 1 |
| 10 | T1190003 Pin, Spring Abutment | Pin, Spring Abutment | 1 | $18.57 | Backorder — Late July 2026 | 1 |
| 11 | T3550444 Washer, 15.5 x 25 | Washer, 15.5 x 25 | 1 | $1.78 | Available to order | 1 |
| 12 | T3550090 Washer, Thrust | Washer, Thrust | 1 | $4.12 | Available to order | 1 |
| 13 | T3500044 E Circlip | E Circlip | 1 | $0.97 | Available to order | 1 |
| 14 | T2082029 Gearchange Pedal Assembly | Gearchange Pedal Assembly | 1 | $135.02 | Available to order | 1 |
| 15 | T2080529 Rubber, Gearchange Pedal | Rubber, Gearchange Pedal | 1 | $8.01 | Available to order | 1 |
| 16 | T2086072 Seal, Ball Joint | Seal, Ball Joint | 1 | $7.66 | Available to order | 1 |
| 17 | T2086073 Clip, Ball Joint | Clip, Ball Joint | 1 | $2.37 | Available to order | 1 |
| 18 | T2082216 Quickshifter Assy, Standard Shift | Quickshifter Assy, Standard Shift | 1 | $458.35 | Out of Stock | Notify Me |
| 19 | T3350308 Nut, M6, Black, LH | Nut, M6, Black, LH | 1 | $1.51 | Available to order | 1 |
| 20 | T2082217 Halfnut, M6, RH Thread | Halfnut, M6, RH Thread | 1 | $2.25 | Available to order | 1 |
| 21 | T2089739 Clamp Assy, Black | Clamp Assy, Black | 1 | $57.95 | Available to order | 1 |
| 22 | T3331614 Bolt, Shld, M8, Slv Enc | Bolt, Shld, M8, Slv Enc | 1 | $10.06 | Available to order | 1 |
| 23 | T3205066 Bolt, HHF, Lghtd, M6 x 20, Slv | Bolt, HHF, Lghtd, M6 x 20, Slv | 1 | $4.55 | Available to order | 1 |
| 24 | T2086082 Clamp Linkage Spares Assembly | Clamp Linkage Spares Assembly | 1 | $117.87 | Available to order | 1 |
| 25 | T2086888 Ball Joint, Left Hand Thread | Ball Joint, Left Hand Thread | 1 | $23.08 | Available to order | |
| 26 | T2082937 Washer, 6.4 x 11 x 1.6 | Washer, 6.4 x 11 x 1.6 | 1 | $1.28 | Available to order | 1 |
| 27 | T2086071 Knuckle, Ball Joint, M6, Enc | Knuckle, Ball Joint, M6, Enc | 1 | $9.72 | Available to order | 1 |
